- Page 1 ASSEMBLY INSTRUCTIONS Description : STURBRIDGE TV CENTER RTA Item No. : TV-51 ITEM NO.: TV-51 Printed in Vietnam REVISED FEB 15, 2019 - 1 -...
- Page 2 BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning assembly, however, make sure all parts and hardware are included and free of obvious defect.
- Page 3 PART LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch Description Sketch Vertical Panel (L-R) Center Panel Center Shelf Side Shelf Door (L-R) (L-R) Side Panel Back Panel...
- Page 4 HARDWARE LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following hardware: Description Sketch Description Sketch Long Bolt Short Pan head screw (M6 x 35mm) (M3.5 x 15mm) Spring Washer Short Screw...
- Page 5 STEP 1 Attach vertical panels (F) to center panel (B) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (11). Attach doors (C) to center panel (B) and bottom panel (E) with door pins (4). Attach vertical panels (F) to bottom panel (E) with bolts (1) as shown below.
- Page 6 STEP 2 Attach side panels (D) to top (A), center panel (B) and bottom panel (E) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (11). STEP 3 Slide back panel (I) into grooves of the side panels (D) and top (A) as shown below. Then attach back panel (I) to the unit with pan head screws (8) as shown below.
- Page 7 STEP 4 Insert brackets (7) to the unit as shown below. Place shelves (G) and (H) on the brackets and attach with screws (9). Tighten with a screwdriver. Attach knobs (6) to doors (C) with pan head screws (5) as shown below. Tighten with a screwdriver. Attach steel bands (14) to the unit with short screws (9) and attach the steel band to the wall with long screws (15) as shown below (to secure the product and prevent tipping).
