- Page 1 ASSEMBLY INSTRUCTIONS : COLONIAL ROCKER Description : R37-120 Item No. Printed in Vietnam ITEM NO: R37-120 ISSUED APR 02, 2015 - 1 -...
-
Page 2: Before Assembly
Remove all wrapping material, including staples & packing straps before you start to assemble. DO NOT tighten all screws and bolts until completely assembled. Keep all hardware parts out of reach of children. ASSEMBLY TOOLS REQUIRED NOT INCLUDED Printed in Vietnam ITEM NO: R37-120 ISSUED APR 02, 2015 - 2 -... -
Page 3: Part List
Lock Washer (10.5 x 8mm) (6.5 x 11mm) Flat Washer Flat Washer (6.5 x 13mm) (6.5 x 19mm) Wood plug Barrel nut (14.5 x 10mm) Allen Key (M4x80mm) Printed in Vietnam ITEM NO: R37-120 ISSUED APR 02, 2015 - 3 -... - Page 4 Then insert wood plugs (8) over bolts to cover them. STEP 2 Attach the Legs (C) to the seat (B) with bolts (1), and washers (4) and (5), as shown below. Tighten with Allen key (9). Printed in Vietnam ITEM NO: R37-120 ISSUED APR 02, 2015 - 4 -...
- Page 5 Then attach arms (G) to the back with bolts (1), and washers (4) and (5) as shown below. Tighten with Allen Key (9). Insert wood plugs (8) over bolts to cover them. Printed in Vietnam ITEM NO: R37-120 ISSUED APR 02, 2015 - 5 -...
