- Page 1 Serious or fatal injuries can occur from furniture tip over. Use tip over restraint (provided) to secure this product to the wall. Description : 48 IN TV STAND Item No : TV-34 ITEM NO.: TV-34 Printed in Vietnam REVISED APR 03, 2020...
-
Page 2: Before Assembly
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the finish of your product. Protect the surface of the product with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: TV-34 Printed in Vietnam REVISED APR 03, 2020... -
Page 3: Part List
Description Sketch Description Sketch Vertical Panel (L-R) Bottom Panel Side Shelf Center Back Center Shelf panel (L-R) Side Back Door (L-R) panel Glass H - Connector Side Panel (L-R) ITEM NO.: TV-34 Printed in Vietnam REVISED APR 03, 2020... -
Page 4: Hardware List
(M4 x 15mm) METAL KNOB (30 x 30mm) Long Pan head GOES WITH screw FINISHED ITEM (M4 x 50mm) ONLY Door pin (5.2/13x1.2mm) Steel Tip Bracket (7x10mm) Magnet Flat Nylon Tie ITEM NO.: TV-34 Printed in Vietnam REVISED APR 03, 2020... - Page 5 STEP 1 Attach glasses (E) to back of doors (D), and lock it. Attach knobs (6) to doors (D) with pan head screws (5) as shown below. Tighten with a screwdriver. ITEM NO.: TV-34 Printed in Vietnam REVISED APR 03, 2020...
- Page 6 Attach magnets (8) to top (A) with pan head screws (9) as shown below. Tighten with a screwdriver. STEP 3 Attach side panels (F) to the unit with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (4). ITEM NO.: TV-34 Printed in Vietnam REVISED APR 03, 2020...
- Page 7 TEP 4 STEP 5 Insert brackets (12) into the unit as shown below. Place shelves (C) and (H) on the brackets and attach with screws (13). Tighten with a screwdriver. ITEM NO.: TV-34 Printed in Vietnam REVISED APR 03, 2020...
- Page 8 Lace the end of flat nylon ties (17) through the larger holes in each mounting bracket. Bring both ends together and slide the flat ends through the locking ends and draw it through until all slack is removed. Confirm that the strap is securely laced and locked. ITEM NO.: TV-34 Printed in Vietnam REVISED APR 03, 2020...
