- Page 1 ASSEMBLY INSTRUCTIONS Description : OLDE WORLD SERVER Item No. : SV-39 ITEM NO.: SV - 39 Printed in Vietnam REVISED JAN 22, 2013 - 1 - THIS ITEM IS PACKED IN 2 CARTONS...
- Page 2 BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning assembly, however, make sure all parts and hardware are included and free of obvious defect. If a part is missing or defective, please contact the store where purchased.
- Page 3 PART LIST SV – 39A When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch Description Sketch Table top Bottom panel PART LIST SV – 39B When unpacking, please be careful not to discard any parts with the packaging.
- Page 4 HARDWARE LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following hardware Description Sketch Description Sketch Short bolt Long bolt (M6x30mm) (M6x50mm) Flat washer Hexagon nut (M8x7mm) (8.5 x 19mm) Lock washer...
- Page 5 STEP 1 Attach side panel (D) to top (A) with bolts (1), washers (6) and (7) as shown below. Tighten with allen key (17). STEP 2 Attach doors (F) (from STEP 1) to top (A) and bottom (B) with door pins (11). Attach bottom panel (B) to side panel (D),) with bolts (1) and washers (6) and (7) as shown below.
- Page 6 STEP 3 Position the side shelf (E) to side panel (D) as shown below. Attach legs (C) to top (A) with washers (4) and (5), and nuts (3). Tighten with the wrench (18). Attach legs (C) to side shelf (E) and bottom panel (B) with bolts (2) and washers (6) and (7) as shown below.
- Page 7 STEP 5 Place the center shelf (I) on the shelf support brackets (8) and secure with screws (14) as shown below. Tighten with a screwdriver. STEP 6 Attach knobs (9) to front of drawers and doors (F) with screws (10). Tighten with a screwdriver. Stick the Warning labels (15) on side of drawers before use.
- Page 8 STEP 7 Attach steel band (13) to the unit with screws (14). Then attach the steel band to a wall with screw (12) as shown below (to secure the product and prevent tipping). ITEM NO.: SV - 39 Printed in Vietnam REVISED JAN 22, 2013 - 8 -...
