- Page 1 ASSEMBLY INSTRUCTIONS Description : HUTCH WITH TWO GLASS DOORS 40X40 Item No. : H-2 ITEM NO.: H-2 Printed in Vietnam REVISED APR 10, 2019 - 1 -...
-
Page 2: Before Assembly
Protect the surface of the product with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: H-2 Printed in Vietnam REVISED APR 10, 2019 - 2 -... -
Page 3: Part List
Bottom shelf Front frame Back panel with doors (Upper) Back panel Base frame (Lower) Back rail Glass (Shelf) Side panel Glass (Door) (L-R) Light Adjustable (light- frame connector) ITEM NO.: H-2 Printed in Vietnam REVISED APR 10, 2019 - 3 -... -
Page 4: Hardware List
Medium screw Steel band (M4 x 30mm) Short screw Knob (M3.5 x 15mm) Long Pan head Allen key screw (M4 x 30mm x 110mm) (M4 x 30mm) ITEM NO.: H-2 Printed in Vietnam REVISED APR 10, 2019 - 4 -... - Page 5 Attach back rail (D) to side panel (E) with pan head screw (8) as shown below. Tighten with a screwdriver. Attach bottom shelf (G) to side panel (E) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (14). ITEM NO.: H-2 Printed in Vietnam REVISED APR 10, 2019 - 5 -...
- Page 6 Attach back rail (D) to side panel (E) with pan head screw (8) as shown below. Tighten with a screwdriver. Attach bottom shelf (G) to side panel (E) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (14). STEP ITEM NO.: H-2 Printed in Vietnam REVISED APR 10, 2019 - 6 -...
- Page 7 Attach front frame with doors (B) to unit with pan head screws (8) as shown below. Tighten with a screwdriver. STEP 6 Attach bottom shelf (G) to front frame (B) with L-brackets (9) and screws (6) as shown below. Tighten with a screwdriver. ITEM NO.: H-2 Printed in Vietnam REVISED APR 10, 2019 - 7 -...
- Page 8 Slide back panel (I) into the grooves as shown below. STEP 8 Attach base frame (C) to unit with screws (5) as shown below. Tighten with a screwdriver. ITEM NO.: H-2 Printed in Vietnam REVISED APR 10, 2019 - 8 -...
- Page 9 Attach crown (A) to the unit with screws (5) as shown below. Tighten with a screwdriver. Attach knobs (13) to front of doors with pan head screws (7) as shown below. Tighten with a screwdriver. Insert glasses (K) into back of doors, and lock it. ITEM NO.: H-2 Printed in Vietnam REVISED APR 10, 2019...
- Page 10 Attach steel band (12) to unit with screws (6) and attach steel band (12) to the wall with screw (5) as shown below (to secure the product and prevent tipping). Tighten with a screwdriver. ITEM NO.: H-2 Printed in Vietnam...
