- Page 1 ASSEMBLY INSTRUCTIONS : 24 IN SLATBACK STOOL Description : S-3012 Item No. ITEM NO.: S-3012 Printed in Vietnam REVISED JUL 03, 2018 - 1 -...
-
Page 2: Before Assembly
Remove all wrapping material, including staples & packing straps before you start to assemble. DO NOT tighten all screws and bolts until completely assembled. Keep all hardware parts out of reach of children. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: S-3012 Printed in Vietnam REVISED JUL 03, 2018 - 2 -... -
Page 3: Part List
(M6 x 80mm) (M4 x 50mm) Short Screw Lock Washer (M4 x 35mm) ()6.5 x 11mm) Flat Washer Allen Key ()6.5 x 19mm) (M4 x 30mm x 110mm) ITEM NO.: S-3012 Printed in Vietnam REVISED JUL 03, 2018 - 3 -... - Page 4 Allen key (8). Attach front stretcher (F) between front legs, and then attach side stretchers (E) to front and back legs with screws (4) as shown below. Tighten with a screwdriver. ITEM NO.: S-3012 Printed in Vietnam REVISED JUL 03, 2018...
- Page 5 STEP 3 Attach seat (C) to top of seat frame (B) with screws (5) as shown below. Tighten with a screwdriver. ITEM NO.: S-3012 Printed in Vietnam REVISED JUL 03, 2018 - 5 -...
