Directed DIRECTECHS FORD12 Installation Manual page 18

Wire Information
Function Color
HS CAN 1 Low (w/o
Gray
OEM Remote Start)
HS CAN 2 High White/Blue or Blue
HS CAN 2 Low White
MS CAN High (w/
Gray/Orange
OEM Remote Start)
MS CAN Low (w/
Violet/Orange
OEM Remote Start)
Lincoln MKZ Hybrid (Smart Key) 2013-2017
Parking Lights Yellow
Parking Lights Interrupt Black/Blue
12V Gray/Red
Ground Black/Blue
HS CAN 1 High (w/o
Green
OEM Remote Start)
HS CAN 1 Low (w/o
Gray
OEM Remote Start)
HS CAN 2 High White/Blue or Blue
HS CAN 2 Low White
MS CAN High (w/
Gray/Orange
OEM Remote Start)
MS CAN Low (w/
Violet/Orange
OEM Remote Start)
18
Pin Polarity Location
17 Data Gateway module on OBDII connector.
20 Data Gateway module on OBDII connector.
19 Data Gateway module on OBDII connector.
23 Data Gateway module on OBDII connector.
22 Data Gateway module on OBDII connector.
11 (-) Headlight switch.
4 Cut Headlight switch.
24 (+) Gateway module on OBDII connector.
14 (-) Gateway module on OBDII connector.
18 Data Gateway module on OBDII connector.
17 Data Gateway module on OBDII connector.
20 Data Gateway module on OBDII connector.
19 Data Gateway module on OBDII connector.
23 Data Gateway module on OBDII connector.
22 Data Gateway module on OBDII connector.
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Directed Digital Solutions FORD12
© 2017-08-17 Directed. All rights reserved.
Pins Ref.
24 B
24 B
24 B
24 B
24 B
16 A
16 A
24 B
24 B
24 B
24 B
24 B
24 B
24 B
24 B
