Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function
Color
Ford Edge (Smart Key) 2015-2017
Parking Lights
Gray
Parking Lights Interrupt
Black/Blue
12V
Gray/Red
Ground
Black/Blue
HS CAN 1 High (w/o
Green/Orange
OEM Remote Start)
HS CAN 1 Low (w/o
Gray/Blue
OEM Remote Start)
HS CAN 2 High
White/Blue or Blue
HS CAN 2 Low
White
MS CAN High (w/
Gray/Orange or Orange
OEM Remote Start)
MS CAN Low (w/
Violet/Orange or Violet
OEM Remote Start)
Ford Explorer (Smart Key) 2016-2017
Parking Lights
Gray
Parking Lights Interrupt
Black/White
12V
Gray/Red
Ground
Black/White
HS CAN 1 High (w/o
Green/Orange
OEM Remote Start)
HS CAN 1 Low (w/o
Gray/Blue
OEM Remote Start)
HS CAN 2 High
White/Blue or Blue
HS CAN 2 Low
White
MS CAN High (w/
Gray/Orange
OEM Remote Start)
MS CAN Low (w/
Violet/Orange
OEM Remote Start)
12
Pin
Polarity
Location
11
(-)
Headlight switch.
4
Cut
Headlight switch.
24
(+)
Gateway module, right of steering column.
14
(-)
Gateway module, right of steering column.
18
Data
Gateway module, right of steering column.
17
Data
Gateway module, right of steering column.
20
Data
Gateway module, right of steering column.
19
Data
Gateway module, right of steering column.
23
Data
Gateway module, right of steering column.
22
Data
Gateway module, right of steering column.
11
(-)
Headlight switch.
4
Cut
Headlight switch.
24
(+)
Gateway module on OBDII connector.
14
(-)
Gateway module on OBDII connector.
18
Data
Gateway module on OBDII connector.
17
Data
Gateway module on OBDII connector.
20
Data
Gateway module on OBDII connector.
19
Data
Gateway module on OBDII connector.
23
Data
Gateway module on OBDII connector.
22
Data
Gateway module on OBDII connector.
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Directed Digital Solutions FORD12
© 2017-08-17 Directed. All rights reserved.
Pins
Ref.
16
A
16
A
24
B
24
B
24
B
24
B
24
B
24
B
24
B
24
B
16
A
16
A
24
B
24
B
24
B
24
B
24
B
24
B
24
B
24
B
