Directed DIRECTECHS FORD12 Installation Manual page 17

Wire Information
Function Color
Lincoln Continental (Smart Key) 2017
Parking Lights Gray
Parking Lights Interrupt Black/Blue
12V Gray/Red
Ground Black/Blue
HS CAN 1 High (w/o
Green/Orange
OEM Remote Start)
HS CAN 1 Low (w/o
Gray/Blue
OEM Remote Start)
HS CAN 2 High White/Blue or Blue
HS CAN 2 Low White
MS CAN High (w/
Gray/Orange
OEM Remote Start)
MS CAN Low (w/
Violet/Orange
OEM Remote Start)
Lincoln MKC (Smart Key) 2015-2017
Parking Lights Gray
Parking Lights Interrupt Black/Violet
12V Gray/Red
Ground Black
HS CAN 1 High (w/o
Green/Orange
OEM Remote Start)
HS CAN 1 Low (w/o
Gray/Blue
OEM Remote Start)
HS CAN 2 High White/Blue or Blue
HS CAN 2 Low White
MS CAN High (w/
Gray/Orange
OEM Remote Start)
MS CAN Low (w/
Violet/Orange
OEM Remote Start)
Lincoln MKX (Smart Key) 2016-2017
Parking Lights Gray
Parking Lights Interrupt Black/Blue
12V Gray/Red
Ground Black/Blue
HS CAN 1 High (w/o
Green/Orange
OEM Remote Start)
HS CAN 1 Low (w/o
Gray/Blue
OEM Remote Start)
HS CAN 2 High White/Blue or Blue
HS CAN 2 Low White
MS CAN High (w/
Gray/Orange
OEM Remote Start)
MS CAN Low (w/
Violet/Orange
OEM Remote Start)
Lincoln MKZ (Smart Key) 2013-2017
Parking Lights Yellow
Parking Lights Interrupt Black/Blue
12V Gray/Red
Ground Black/Blue
HS CAN 1 High (w/o
Green
OEM Remote Start)
17
Pin Polarity Location
11 (-) Headlight switch.
4 Cut Headlight switch.
24 (+) Gateway module on OBDII connector.
14 (-) Gateway module on OBDII connector.
18 Data Gateway module on OBDII connector.
17 Data Gateway module on OBDII connector.
20 Data Gateway module on OBDII connector.
19 Data Gateway module on OBDII connector.
23 Data Gateway module on OBDII connector.
22 Data Gateway module on OBDII connector.
11 (-) Headlight switch.
4 Cut Headlight switch.
24 (+) Gateway module on OBDII connector.
14 (-) Gateway module on OBDII connector.
18 Data Gateway module on OBDII connector.
17 Data Gateway module on OBDII connector.
20 Data Gateway module on OBDII connector.
19 Data Gateway module on OBDII connector.
23 Data Gateway module on OBDII connector.
22 Data Gateway module on OBDII connector.
11 (-) Headlight switch.
4 Cut Headlight switch.
24 (+) Gateway module, right of steering column.
14 (-) Gateway module, right of steering column.
18 Data Gateway module, right of steering column.
17 Data Gateway module, right of steering column.
20 Data Gateway module, right of steering column.
19 Data Gateway module, right of steering column.
23 Data Gateway module, right of steering column.
22 Data Gateway module, right of steering column.
11 (-) Headlight switch.
4 Cut Headlight switch.
24 (+) Gateway module on OBDII connector.
14 (-) Gateway module on OBDII connector.
18 Data Gateway module on OBDII connector.
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Directed Digital Solutions FORD12
© 2017-08-17 Directed. All rights reserved.
Pins Ref.
16 A
16 A
24 B
24 B
24 B
24 B
24 B
24 B
24 B
24 B
16 A
16 A
24 B
24 B
24 B
24 B
24 B
24 B
24 B
24 B
16 A
16 A
24 B
24 B
24 B
24 B
24 B
24 B
24 B
24 B
16 A
16 A
24 B
24 B
24 B
