The Provisioning Screen, illustrated in Figure 7,
displays the current provisioning settings for the
HDSL2 circuit. To change a particular option setting,
select the appropriate number and a new menu will
appear with a list of the available settings.
CIRCUIT ID:
CIRCUIT ID:
8
Press ESC to return to previous menu
Provisioning
1. DSX-1 Line Buildout
2. DSX-1/DS1 line code
3. DSX-1/DS1 framing
4. NIU Loopback
5. NEW ENGLAND 1:6 LPBK
6. Loopback Timeout
7. Latching Loopback Mode
8. DS1 TX Level
9. Customer Loss Indicator =
10. PRM Setting
11. Loop Atten Alarm Thres
12. SNR Margin Alarm Thres
SELECTION:

Figure 7. Provisioning Screen

Press ESC to return to previous menu
Span Status Screen
ATTEN
______ <-29dB->
|H2TUC |
<------| |
| |
NET | |<--------->|
| |09dB
------>| | MARGIN
DSX-1 |______|
1. Legend
2. Detailed Status
Selection:

Figure 8. Span Status Screen

61222026L1-5, Issue 1
The Span Status Screen, illustrated in Figure 8,
provides quick access to status information for each
HDSL2 receiver in the circuit. The Legend selection
provides a description of the messages that are used on
the Span Status Screens.
= 0-133 FEET
= B8ZS
= Auto
= Enabled
= Disabled
= 120 Min
= T1 (Disabled)
= -7.5 db
AIS / CI
= none
= 40db
= 04db
______
|H2TUR |
| |------>
| |
| CUST
10dB| |
| |<------
|______| DS1
01/01/00 00:03:51
01/01/00 00:04:23
