Figure 11. 15-Minute Performance History Path Data Screen - ADTRAN T200 H2TU-R Installation And Maintenance Manual

The Performance History Screens, illustrated in
Figure 11, Figure 12, and Figure 13 display the
historical HDSL2 and T1 performance data in several
different registers. At each 15-minute interval, the
performance information is transferred to the
15-minute performance data register. This unit stores
performance data in 15-minute increments for the last
24-hour period. Additionally, some units store up to
48 hours worth of 60-minute interval data.
CIRCUIT ID:
1. Definitions
2. Reset Data
3. 15 Min Data
4. 60 Min Data
5. 24 Hr Data
6. Line Data
7. Path Data
8. H2TUC DSX-1
9. H2TUC LOOP
10. H2TUR LOOP
11. H2TUR DS1

Figure 11. 15-Minute Performance History Path Data Screen

10
Press ESC to return to previous menu
Menu 15 Minute H2TUC DSX-1 Performance Data
00:00 000
23:45 000
23:30 000
23:15 000
23:00 000
22:45 000
22:30 000
22:15 ---
22:00 ---
21:45 ---
21:30 ---
21:15 ---
Selection:
61222026L1-5, Issue 1
At each 24-hour interval, the performance data is
transferred into the 24-hour performance data
registers. This unit stores up to 31 days of 24-hour
interval data.
The user is prompted to select a module and interface
to view the corresponding performance data. Line (L)
and Path (P) related data can be viewed.
