S15: Max Fan Free Setting
Cooling
S16: Min Fan Cooling Setting
S17: Max Fan Cooling Setting
S18: Cooling release Setting
S19: Thermostat ID Setting
S20: Control Setting
S21: Modbus Address Setting
S22: Modbus Baudrate Setting
S23: Modbus Parity Setting
S24: Drain Valve Setting
S25: Water Desinfection Setting
S26: Digital Input J12 Setting
S27: Winter Model Setting
S28: Model Setting
S29: Serialnumber Setting
S30: Language Setting
S31: Factory Setting Setting
5.2.6
Version 1.3, 2021-12-14
84 76
30 30
84 76
15 15
2 2
Thermostat Thermostat
1 1
19200 19200
8N1 8N1
2-wire N.O. 2-wire N.O.
None None
Not used Not used
Off Off
- -
- -
English English
- -
Error codes on OxyLogic LCD
Reset error: Press the reset button [3] located directly below the OxyLogic LCD
(left side).
Operation procedures
% Maximum fan speed for free-cooling
% Minimum fan speed for cooling
% Maximum fan speed for cooling
°C Minimum outdoor temperature for
cooling. At a cooling demand below this
temperature, the system will switch to
free-cooling.
Thermostat Modbus ID (corresponding
thermostat).
Control type.
Unit modbus ID.
Unit modbus baudrate.
Unit modbus parity.
Configure drain valve type (older units
have 3-wire valves, new units have 2-wire
valve).
UV-C Lamp on / off. (Optional)
Select function of digital input J12: Not
used / AHU pre-cooling / Fire contact.
Enable / disable winter mode - winter
mode enables free-cooling instead of
cooling.
Set model type.
Set serial number.
Set display menu language.
Load factory settings (saving settings
required to activate).
1
2
3
4
5
