Support Frame (Not Provided); Ducting - oxycom IntrCooll Std. Manual

3.2
22
1 Breather vent pipes or sewer pipes
2 Solid heater flue pipes
3 3Walls or air blocking obstacles
Exhaust air openings
Neighboring residences
TV antenna

Support frame (Not provided)

Note
When not used in combination with a Flashing Kit (optional) on page 23 or a
Natural Ventilator module (optional), the contractor shall provide a support
frame for the IntrCooll®.
As an option a support frame can be ordered at Oxycom:
- Article no. 5301251, support frame for IntrCooll® Std.
- Article no. 5301305, support frame for IntrCooll® Plus
Refer to the accessories brochure for more information on the optional support
frame.
If the contractor provides a support frame, Oxycom recommends the use of a
support frame with the following specifications:
- The profile for the welded frame is galvanized steel "L".
- profile of 40 mm x 40 mm x 3 mm.
- The support frame should have a loading capacity of at least the wet weight
of the unit.
- Unit must be placed/positioned 100% level. If not level, water might leak into

ducting.

Minimum height:
- Std.: 400 mm.
- Plus: 500 mm.
5000 mm
3000 mm
600 mm
10 000 mm
Local regulations
5000 mm
