oxycom IntrCooll Std. Manual page 38

3.16.2
38
2 Types of thermostats are available:
Temperature
control
Non-programmable Yes
Thermostat
Programmable Yes
Thermostat
Example of a programmable thermostat and of a non-programmable thermostat
Each thermostat has 3 operation modes with manual or automatic switch over:
- Heat reclaim (only applicable/used when a Heat Reclaim module is ordered).
- Free cooling (fan only).
- Cooling.
Note
The thermostat must not be mounted to an exterior wall, close to a heat source
or in a supply airflow of the IntrCooll®.
Note
It is advised to install an insulated plate on the back of the thermostat to
minimize radiation from the wall.
Oxyconnect gateway control
Oxyconnect gateway control allows the control of multiple IntrCooll®s by one (or
more) thermostats. It also provides for remote monitoring, configuration and
control (ethernet connection required).
Oyxconnect gateway is a cloud-based portal with real-time data of all units.
To control the IntrCooll® by Oxyconnect gateway the contractor must provide the
following:
- An enclosure for the power supply of the gateway control box.
- An automated fuse of 0.5A.
Humidity limit Time schedule
sensor
No No
Yes Yes
