1 Delivery of the crate and transport to the installation site
A Is there a place indoor where the crated equipment can be stored
temporarily?
B Is there a fork-lift truck or any other lifting device available with
proper lifting gear/ropes according to manual?
Remarks:
2 Installation requirements
A Minimum free space for 1 side of 600 mm?
B Minimum free space for 3 or more sides of 1000 mm?
C There are no obstacles (i.e exhaust vents/fans, sewer pipe vents)
near equipment.
D If the unit is placed/elevated more than 1.5 m above roof/floor, a
service platform with minimum free space (see 2.A and 2.B) is
provided?
Remarks:
3 Equipment installation
A Support frame(s) for IntrCooll®
(not applicable for optional Flashing Kit or Natural Ventilator
module)
B Equipment will be placed level (to prevent water leakage in
ducting)
C Watertight roof transit for ducting
D Water tight roof transit for cabling/water pipes
E Roof beam supports are calculated/constructed such that they can
hold weight of IntrCooll® in operation (wet)
F Ducting diameter/dimensions according to specifications?
Version 1.3, 2021-12-14
YES NO Reference
Handling and storage
o o
Transport
o o
YES NO
Space
o o
requirements on page 20
Space
o o
requirements on page 20
Location
o o
requirements on page 20
o o
YES NO
Support frame (Not provided)
o o
Roof transit for
o o
ducting on page 26
Roof transit for
o o
ducting on page 26
Roof transits for cabling /
o o
plumbing on page 26
Roof beam
o o
supports on page 24
Opening and curb on page 24
o o
Install the IntrCooll®
1
2
3
4
5
