oxycom IntrCooll Std. Manual page 54

5.1.3
54
Power-up unit and final checks and settings
Main switch
1. Main switch
1. Check if water and electricity are connected.
2. Remove the cover from the electric component section.
Danger
Electric shock hazard while working on electric components.
3. Power up the unit by turning the main switch (1) on. The OxyLogic display will
light up and the unit will start-up. It can take up to several minutes until the
unit will start depending on the settings.
4. Remove the cover of the pump section.
5. Check if the pump rotates in the right direction. The arrow on top shows the
direction (counterclockwise). If this is not correct it must be corrected, refer to
the wiring diagram for the correct connection.
6. Install the cover of the pump section.
