G Minimum free space for 3 or more sides of 1000mm?
H Modulating exhaust air vents/fans including cabling are accounted
for?
(might require roof support beams as well)
Remarks:
4 Electrical specifications
A Electrical supply phases/voltage/frequency meets equipment
requirements?
B External power supply fuse for each unit
C Power isolating (padlock) switch provided for each unit (preferable
on the roof near the equipment)
D Power supply cable meets specifications and local regulations
E Power supply cable connected correctly?
F Power supply cable of equipment (maximum 1.5m) will be
connected to an external terminal box, so that equipment can
easily be disconnected, when necessary.
G Equipment will be earthed.
H Main power outlet for service / maintenance available on the roof /
in close proximity to equipment?
I Correct flow regulator cap mounted? 50 Hz standard, exchange if
necessary for 60 Hz use.
Remarks:
5 Communication specification
A Is thermostat ordered for each IntrCooll®? Not applicable if
connected to optional OxyConnect gateway or BMS system.
B Thermostat mounted on a suitable spot?
50
Space
o o
requirements on page 20
Exhaust air on page 27
o o
YES NO
Electrical
o o
requirements on page 36
Power supply fuse on page 36
o o
Power isolating
o o
switch on page 36
Electrical
o o
connections on page 47
Electrical
o o
connections on page 47
o o
Electrical
o o
connections on page 47
Mains power outlet on page 37
o o
Step 5. Flow regulator
o o
cap on page 45
YES NO
Communication
o o
requirements on page 37
Thermostat control on page 37
o o
