AD9286-500EBZ User Guide
Qty Reference Designator
22 R405, R407, R408, R414,
R415, R416, R417, R449,
R450, R504, R507, R508,
R509, R510, R516, R517,
R520, R521, R522, R523,
R601, R602
4 R410, R411, R412, R413
1 R436
1 R437
4 R438, R439, R440, R441
2 R442, R443
4 R505, R506, R518, R519
2 RN601, RN602
1 T401
2 T502, T504
1 U101
1 U102
1 U201
1 U301
1 U302
1 U401
Description
Film SMD 0402 resistor
Film SMD 0402 resistor
Precision thick film chip 0402 resistor
Precision thick film chip 0402 resistor
Precision thick film chip 0402 resistor
Film SMD 0402 resistor
Precision thick film chip 0402 resistor
Network 16-pin/8res surface-mount
resistor
XFMR RF, MINICD542
XFMR RF 1:1 (6-pin special) ETC1-6P
Compact, 600 mA, 3 MHz, TSOT-5
step-down dc-to-dc converter
Compact, 600 mA, 3 MHz, TSOT-5
step-down dc-to-dc converter
Analog-to-digital converter
IC tiny logic UHS dual buffer
IC tiny logic UHS dual buffer
Ultralow distortion differential ADC
driver
Rev. A | Page 23 of 24
Value Manufacturer/Part No.
0 Ω Panasonic/ERJ-2GE0R00X
33 Ω Panasonic/ERJ-2GEJ330X
61.9 Ω Panasonic/ERJ-2RKF61R9X
27.4 Ω Panasonic/ERJ-2RKF27R4X
200 Ω Panasonic/ERJ-2RKF2000X
24 Ω Panasonic/ERJ-2GEJ240X
24.9 Ω Panasonic/ERJ-2RKF24R9X
0 Ω Panasonic/EXB-2HVR000V
ADT1-1WT+ Minicircuits/ADT1-1WT+
MABA-007159-000000 Macom/MABA-007159-000000
ADP2108AUJZ-3.3-R7 Analog Devices/
ADP2108AUJZ-3.3-R7
ADP2108AUJZ-1.8-R7 Analog Devices/
ADP2108AUJZ-1.8-R7
AD9286BCPZ-500 Analog Devices/
AD9286BCPZ-500
NC7WZ07P6X Fairchild/NC7WZ07P6X
NC7WZ16P6X Fairchild/NC7WZ16P6X
ADA4937-1YCPZ-R7 Analog Devices/
ADA4937-1YCPZ-R7
