Assembly Instructions:
Assembly Instructions:
To purchase parts or accessories, please contact us at
To purchase parts or accessories, please contact us at
www.spectrumfurniture.com
www.spectrumfurniture.com
1-800-235-1262
1-800-235-1262
Thank you for choosing Spectrum products!
Thank you for choosing Spectrum products!
(8) 026073
(8) 026073
#8 x 3/4" PHSM Screws
#8 x 3/4" PHSM Screws
(4) 044541
(4) 044541
1/4-20 x 20mm JC Bolts
1/4-20 x 20mm JC Bolts
(8) 0100167
(8) 0100167
#8 x 1/2" PH Thrd
#8 x 1/2" PH Thrd
Ctg Screws
Ctg Screws
Before you begin, please make sure all parts and proper quantities are
Before you begin, please make sure all parts and proper quantities are
included. Any parts damaged during shipment must be reported within
included. Any parts damaged during shipment must be reported within
15 days of receipt. To report information regarding damages or if you
15 days of receipt. To report information regarding damages or if you
have any questions, please call 1-800-235-1262.
have any questions, please call 1-800-235-1262.
1. Attach support brackets
1. Attach support brackets
A. Attach the left and right support brackets to the LINK cart as
A Att
h th l ft
d i ht
shown using (2) 1/4-20 x 20mm JC bolts per bracket. Figure 1.
B. Do not tighten the JC bolts completely yet.
Figure 1
2. Attach folding brackets
A. Determine the height you would like the shelf to be mounted.
B. Open each folding bracket, and align the mounting holes at the desired height.
C. With an electric drill, driver extension, and #1 Phillips driver, attach each folding bracket to the support brackets
with (3) #8 x 1/2" PHSM screws. Tighten securely, but be careful not to strip out the holes. Figure 2.
(2) 056886
(2) 056886
12" x 8" Folding Brackets
12" x 8" Folding Brackets
(1) 039622
(1) 039622
(1) 025039
(1) 025039
2" Grommet
2" Grommet
4mm Hex Wrench
4mm Hex Wrench
t b
k t t th LINK
Attached with (2) JC bolts
(Do not tighten completely)
LINK Cart Document Camera Shelf
LINK Cart Document Camera Shelf
t
Support Bracket
Folding Bracket
#8 x 1/2" PHSM screws
(3 per bracket)
#55140
#55140
Tools Required:
Tools Required:
4mm hex wrench (included)
4mm hex wrench (included)
Phillip screwdriver
Phillip screwdriver
Electric drill w/ #1 Phillips driver + extension
Electric drill w/ #1 Phillips driver + extension
Figure 2
050581XR6 Page 1 of 2
