AJAX ReX 2 User Manual page 9

5. You have administrator rights for this hub.
6. The hub has internet access via at least one communication channel:
Ethernet, Wi-Fi, or a cellular connection. You can check this in the Ajax app
or through the hub logo on the faceplate. The logo should light up white or
green.
7. The hub is disarmed and is not being updated. You can check this through
the status of the hub in the Ajax app.
In order to connect ReX 2 to the hub:
1. Remove the SmartBracket mounting panel by sliding it down with force. Do
not damage the perforated portion as it is needed to trigger the tamper
protecting the range extender from dismantling.
2. Connect ReX 2 to external power supply. Connect an Ethernet cable to ReX
2.
3. Sign in to the Ajax app.
4. Select the hub if you have several of them or if you are using a PRO app.
5. Go to the Devices
6. Name the range extender, scan or enter the QR code manually (indicated on
the device body and packaging), and select a room and a group (if the
mode is activated).
tab and click Add Device.
group
