AJAX ReX 2 User Manual page 14

Connection via Jeweller
Ethernet
Wings Signal Strength
Connection via Wings
Radio transmitter power
Learn more
Connection status between the hub and ReX 2
range extender via Jeweller:
Online — the range extender is connected.
O ine — no connection to the range
extender.
Status of connection between the hub and the
ReX 2 range extender via Ethernet:
Connected — the range extender is
connected.
Not connected — no connection with the
range extender.
Disabled — Ethernet connection is disabled
in the range extender settings.
Pressing the button displays the connection
information: IP Address, Subnet Mask, Gateway,
and MAC Address of the range extender.
Wings signal strength between the hub and ReX
2. Recommended values — 2-3 bars.
Wings is a protocol for transmitting photos
taken by the detectors with photo veri cation.
Learn more
Status of connection between the hub and the
ReX 2 range extender via Wings:
Online — ReX 2 can transmit photos to the
hub.
O ine — ReX 2 cannot transmit photos to
the hub.
The eld is displayed if the Attenuation Test is
enabled.
Maximum — the maximum power of the
radio transmitter is set in the Attenuation
Test.
