Lights up red.
Lights up for 3 minutes, then
ashes every 10 seconds.

Functionality testing

ReX 2 functionality tests do not begin immediately, but not later than over a
single ping period of the hub–detector (36 seconds with the standard settings
of the hub). You can change the ping period of devices in the Jeweller menu of
the hub settings.
To run a test, in an Ajax app:
1. Select the hub if you have several of them or if you are using a PRO app.
2. Go to the Devices
3. Select ReX 2.
4. Go to Settings
5. Select one of the available tests:
Jeweller Signal Strength Test
Wings Signal Strength Test
Signal Attenuation Test

Selection of the installation site

2. Ethernet
No communication with the
hub.
The external power supply is
disconnected.
tab.
.
If the external power supply is
off, the indicator will ash
every 10 seconds.
The colour of the indication
depends on the presence of
connection to the hub.
