ReX is a range extender of communication signals that expands the radio
communication range of Ajax devices fitted with a hub up to 2 times. Developed
only for indoor use. It has a built-in tamper resistance and is equipped with a
battery that provides up to 35 hours (up to 24 hours is evaluated by UL) of
operation without external power.
The extender is compatible only with the
ocBridge Plus
The device is configured via the
smartphones. Push-notifications, SMS messages and calls (if enabled) notify
ReX user about all events.
Only
Hub 2 Plus Jeweller
standards.
ReX User manual
Updated June 17, 2024
* is not provided.
mobile application
and
Hub 2 (4G) Jeweller
Ajax hubs
! Connection to
for iOS and Android
are certified according to UL/ULC
uartBridge
* and
Advertisement
Related Manuals for AJAX ReX
Summary of Contents for AJAX ReX
- Page 1 ReX is a range extender of communication signals that expands the radio communication range of Ajax devices fitted with a hub up to 2 times. Developed only for indoor use. It has a built-in tamper resistance and is equipped with a battery that provides up to 35 hours (up to 24 hours is evaluated by UL) of operation without external power.
-
Page 2: Functional Elements
The Ajax system can be used for independent monitoring of the site and can be connected to the Central Monitoring Station of the security company. * Not evaluated by UL. Buy range extender ReX Functional elements 1. Logo with light indicator 2. - Page 3 5 ReX Connecting multiple ReX to the hub is supported by devices with OS Malevich 2.8 and later. At the same time, ReX can only be connected directly to the hub and connecting one range extender to another is not supported.
- Page 4 ReX does not increase the number of devices connected to the hub! * Certified according to UL/ULC standards. Connection of ReX to the hub Before adding a device: 1. Install the Ajax app Ajax PRO 2. Log in to an account or create a new one.
- Page 5 3. Click Add — the countdown begins. 4. Turn on ReX by pressing the power button for 3 seconds — shortly after connecting to the hub the logo will change its color from red to white within...
- Page 6 In order for detection and interfacing to occur, ReX must be located within radio communication range of the hub (on the same guarded facility). The request to connect to the hub is transmitted only when the device is enabled. If the connection to the hub fails, turn off the extender by pressing the power button for 3 seconds and retry the connection procedure after 5 seconds.
- Page 7 Wings radio protocol. A device can only be paired with one ReX. When a device is assigned to a range extender it is automatically disconnected from another connected range extender.
- Page 8 Shows the status of the device: active, completely disabled by the user, or only Permanent Deactivation notifications about triggering of the device tamper button are disabled Firmware ReX firmware version Device ID Identifier of the device ReX settings 1. Devices 2. ReX 3.
- Page 9 Learn more about permanent deactivation of devices Note that the system will ignore only the disabled device. Devices connected via ReX will continue operating normally User Guide Opening ReX User Manual Disconnecting the extender from the hub and...
-
Page 10: Functionality Testing
Indication The ReX LED indicator may light red or white depending on the state of the device. Event State of logo with LED indicator Device is connected to the hub Constantly lights white Device lost connection with the hub Constantly lights red... -
Page 11: Device Installation
Take whatever action is necessary to improve the quality of the signal! At the very least, move ReX or hub — relocation even by 20 cm can significantly improve the reception quality. -
Page 12: Installation Procedure
2. Slide ReX onto the attachment panel. After installation, check the tamper status in the Ajax application and then the panel tightness. 3. In order to ensure higher reliability, fix ReX to the SmartBracket panel with the bundled screws. Do not flip the range extender when attaching vertically (for instance, on a wall). -
Page 13: Maintenance Of The Device
It is strictly forbidden to disassemble the device connected to the power supply! Do not use the device with a damaged power cable. Do not disassemble or modify ReX or its individual parts — this may interfere with the normal operation of the device or lead to its failure. -
Page 14: Complete Set
4. Installation kit 5. Quick start guide Warranty Warranty for the Limited Liability Company “Ajax Systems Manufacturing” products is valid for 2 years after the purchase and does not apply to the pre- installed accumulator. If the device does not work correctly, contact the support service first —... - Page 15 Subscribe to the newsletter about safe life. No spam Email Subscribe...
