AJAX ReX 2 User Manual page 21

00:00
The ReX 2 LED indicator may light up white, red, or green, depending on the
status of the device and connection via Ethernet.
Indication when connection via Ethernet is disabled
Indication
Lights up white.
Lights up red.
Lights up for 3 minutes, then
ashes every 10 seconds.
Indication when connection via Ethernet is enabled
Indication
Lights up white.
Lights up green.
Event
Connection is established with
the hub through at least one of
the channels: Jeweller and/or
Wings.
No communication with the
hub.
The external power supply is
disconnected.
Event
Connection is established with
the hub via two channels:
1. Jeweller and/or Wings.
2. Ethernet
Connection is established with
the hub via two channels:
1. Jeweller and/or Wings.
00:06
Note
If the external power supply is
off, the indicator will ash
every 10 seconds.
If the external power supply is
off, the indicator will ash
every 10 seconds.
The colour of the indication
depends on the presence of
connection to the hub.
Note
If the external power supply is
off, the indicator will ash
every 10 seconds.
If the external power supply is
off, the indicator will ash
every 10 seconds.
