Unitronics Vision OPLC V1040-T20B User Manual page 13

Installation Guide
I/Os
Snap-in I/O modules
Expansion modules
Exp. port isolation
Dimensions
Size
Weight
Notes:
6. For exact dimensions, refer to the product's Installation Guide.
Mounting
Panel-mounting
Environment
Inside cabinet
Panel mounted
Operational temperature
Storage temperature
Relative Humidity (RH)
The information in this document reflects products at the date of printing. Unitronics reserves the right, subject to all applicable laws, at any time, at its sole
discretion, and without notice, to discontinue or change the features, designs, materials and other specifications of its products, and to either permanently or
temporarily withdraw any of the forgoing from the market.
All information in this document is provided "as is" without warranty of any kind, either expressed or implied, including but not limited to any implied warranties of
merchantability, fitness for a particular purpose, or non-infringement. Unitronics assumes no responsibility for errors or omissions in the information presented in
this document. In no event shall Unitronics be liable for any special, incidental, indirect or consequential damages of any kind, or any damages whatsoever arising
out of or in connection with the use or performance of this information.
The tradenames, trademarks, logos and service marks presented in this document, including their design, are the property of Unitronics (1989) (R"G) Ltd. or other
third parties and you are not permitted to use them without the prior written consent of Unitronics or such third party as may own them.
Unitronics
Number of I/Os and types vary according to module. Supports up to
1024 digital, high-speed, and analog I/Os.
Plugs into rear port to create self-contained PLC with up to 62 I/Os.
Local adapter (P.N. EX-A1), via I/O Expansion Port. Integrate up to 8
I/O Expansion Modules comprising up to 128 additional I/Os.
Remote adapter (P.N. EX-RC1), via CANbus port. Connect up to 60
adapters; connect up to 8 I/O expansion modules to each adapter.
Galvanic
289X244.5X59.1mm
1.5kg (52.9 oz)
Via brackets
IP20 / NEMA1 (case)
IP65 / NEMA4X (front panel)
0 to 50ºC (32 to 122ºF)
-20 to 60ºC (-4 to 140ºF)
5% to 95% (non-condensing)
) 11.37 " 9.62 X2.32"). See Note 6 "
X
Vision™ OPLC™ V1040-T20B
UG_V1040-T20B.pdf 07/22
13
