Digidrive V2

6.0........................................................Operating the Digidrive V2

6.1................................................................Channel Select

Using the –CH SELECT and CH SELECT+ buttons, users
can select the channel(s) to control. This can be Input
AB, CD, Output 12, 34, 56 or Input A, B, C, D, Output 1, 2,
3, 4, 5, 6.

6.2.................................................................Input Menus

Each input channel has a set of Menus for specific parameters,
accessed with the –PAGE and PAGE+ buttons.
Gain, -48.00dB (mute) to +12.00dB, in 0.25dB steps.
Delay, 0ms to 2000ms in 0.01ms steps. By depressing
the control wheel, units can be changed to feet or mm.
Low Pass, 20Hz to 20kHz (off), in 1, 10, 50 and 100Hz
steps. By depressing control wheel , users can enable/
disable it and change the Filter Type.
13
In A Gain
00.00dB
In A Delay
000.000ms
In A LowPass
Freq: 80Hz
User Manual
