Digidrive V2
Access Level, Unlocked or ****Locked****. This allows
the user to secure the unit and prevent changes on the
device. To lock/unlock the device a password is required
by depressing the control wheel. To delete a character
whilst entering a password, the EXIT button is pressed.
Press the menu button once the password has been
entered to confirm it, and then again to set it.
NOTE: Locking the unit will lock any parameters from being
changed. To unlock the unit in order to make further changes, use
the same process required to lock the device with the same
password entered.
Version Info/IP Address/MAC Address, information for
the user about the device. Includes Serial Number,
software version, hardware version, IP address and
MAC address.
Routing, changes the configuration of the device:
MODE
Stereo 1-way
Stereo 2-way
Stereo 3-way
3-channel 1-way
3-channel 2-way
4-channel 1-way
Mono 4-way
Mono 5-way
Mono 6-way
17
Access Level :
Unlocked
Version Info
SN: XXXXXXXXXXXXX
IP Address
XXX.XXX.XXX.XXX
Out 1 Out 2
In1 In2
In1 In1
In1 In1
In1 In2
In1 In1
In1 In2
Any Any
Any Any
Any Any
Out 3 Out 4
In2 In2
In1 In2
In3
In2 In2
In3 In4
Any Any
Any Any
Any Any
Out 5 Out 6
In2 In2
In3 In3
Any
Any Any
