MANUAL: Press and release for fog on demand
The menu options displayed on the wired remote are as follows:
Function
Heating status
Bubble control
Interval
Duration
DMX512
Volume
Red
Green
Blue
Glint
Skip
Gradual
Operation: Wireless remote
The small RF remote control supplied can also be used when wireless control of the unit is
needed. Ensure the wired remote control is connected to the unit, to use the RF remote for
the following functions:
Operation: DMX Control
For DMX control, connect a signal source to the DMX input on the unit via a balanced XLR
lead. Extra units can also be controlled with the same DMX signal by looping through the DMX
out on the unit. Set the unit to DMX512 mode and confirm the correct start address, then use
the table below for channel selection.
www.avsl.com
Selection Content
Warming Up Unit warming up please wait
Ready to Work Unit is ready to use
Bubble ON Bubble flow on
Bubble OFF Bubble flow off
Set 1-200 Set interval of fog time
Set 1-200 Set continuous fog duration
Add 1-512 Set DMX address
Set 0-100 Set fog output volume (low to high)
Set 0-100 Set Red LED Light effect (dark to bright)
Set 0-100 Set Green LED Light effect (dark to bright)
Set 0-100 Set Blue LED Light effect (dark to bright)
Set 0-100 Set LED strobe effect (slow to fast)
Set 0-100 Set LED colour change (slow to fast)
Set 0-100 Set LED colour fade (slow to fast)
1: Press for fog effect on/off
2: Press for bubbles on/off
3: Press for LED colour range/off
4: Press for LED colour change/fade/off
