Courtyard Creations KTS6463-WM Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
KTS6463-CS02-1
2
62KTS6463Q101
3
KTS6463-CS04-3
4
KTS6463-CS04-4
5 17C33A0706001Y4
Attention:
Make sure that each bolt needed for all steps matches
the corresponding figure to ensure proper assembly.

Step 1:

Place the left leg (#3) onto a non-abrasive surface, such
as a carpet, with its underside facing upwards. Fasten
the supports (#2) to the left leg (#3) and the right leg
(#4) by using bolts (#5) and washers (#7). Keep the
bolts loose. See Figure 1.
Note:
The labels marked "L" and "R" on legs (#3 and #4)
should coincide with Figure 1 to ensure proper assembly.
!
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
KTS6463-
PART
SEAT ASSEMBLY
SUPPORT
LEFT LEG
RIGHT LEG
BOLT M6*16
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 2
WM
PART
QTY MATERIAL CODE
NO.
1 6
17C01A0712001Y4
3 7
17FA05040301-Y4
1 8
18000337004
1 9
18000337001
10
12 17KAA0101----Y4
FIGURE 1
4
R
2
3
L
PART
BOLT M6*35
WASHER d6.5*D13*1.0
BOLT CAP
BOLT CAP M6
HEX.KEY WRENCH 4MM
8
2
5
2
7
16
#5 BOLT M6*16
COURTYARD CREATIONS INC.
QTY
4
16
12
4
1
8
5
7
