ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
!
Use the correct bolts as indicated. Do not tighten any of the bolts until the swing is completely
assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
RUS426K-
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 7
WM
COURTYARD CREATIONS INC.

Advertisement

loading
Need help?

Need help?

Do you have a question about the RUS426K-WM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Courtyard Creations RUS426K-WM

Summary of Contents for Courtyard Creations RUS426K-WM

  • Page 1 Children should always be under direct adult supervision while using this product. Retain these assembly instructions for future reference. Quote the following FQC NO. when contacting the service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 DON’T RETURN TO STORE! STOP COURTYARD CREATIONS INC. PAGE 1 OF 7...

  • Page 2: Parts List

    A. Read the instructions thoroughly. Acquaint yourself with the inventory of parts and the accompanying drawings to ensure safe and proper assembly. B. You will need the following tools: - Phillips Screwdriver - Nut Wrench (See Part #35) - Hex. Key Wrench (See Part #34) C.
  • Page 3 Note: When fastening with bolts and nuts, always use a washer (#22 and #23) between the tube and the bolt and the tube and the nut. Step 2 Step 1: Step 1 Fasten the front and rear upright support (#2 and #3) at the top, by using bolts (#17), washers (#22), and plastic nuts (#25).
  • Page 4 Step 6: Insert the front/rear canopy braces (#6) into the sleeves on the canopy (#36). See Fig. C – Step 3. Step 3 Step 7: Insert the front/rear canopy brace (#6) tube ends into the U-shaped side canopy braces (#7). See Fig.
  • Page 5 Step 10: Step 1 Place the left seat assembly (#8) and the right seat assembly (#9) onto a non-abrasive surface, such as a carpet. Fasten the front support brace (10) to the left seat assembly (#8) and the right seat assembly (#9) by using bolts (#17), washers (#22), and nuts (#26).
  • Page 6 Step 14: Hook the suspension springs (#15) into the top of both holes in the swing arm tubes (#14). Repeat the same procedure for both sides. See Fig. G. Fig. G Step 15: Hang the other ends of the suspension springs (#15) into the holes located in the angled brace on the top cross beam w/adjustable teeth (#1).

  • Page 7: Cleaning And Maintenance

    Cleaning and Maintenance • Wash frame and fabric parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach, acid, or other solvents on the frame or fabric. • The cushions and canopy may be surface washed with mild soap and water if necessary. Commercial foaming upholstery cleaner may also be used.
