ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
Easton 5PK Padded Spring Action Sling Chairs

PARTS LIST

PART
MATERIAL CODE
NO.
1
KTS6057-CS01
2
KTS6057-CS02
3
17C01A0712001Y4

Step 1:

At the front of the chair, fasten the seat assembly
(#1) to the base assembly (#2) by using bolts (#3)
and washers (#4). Keep the bolts loose.
See Figure 1.
!
Do not discard any of the packaging until you have checked that you have all the parts and pack
of fittings.
!
Keep children away during assembly. This item contains small parts which can be swallowed by
children. Children should always be under direct adult supervision while using the product.
!
Retain the assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
KTS6057
PART
Q'TY
1
SEAT ASSEMBLY
1
BASE ASSEMBLY
4
BOLT M6*35
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
PAGE 1 OF 2
4
17FA05040301-Y4
5
1808010205301
6
18000337001
7
17KAA0101----Y4
FIGURE 1
2
1
COURTYARD CREATIONS INC.
4
WASHER d6.5*D13*1.0
2
PLASTIC CAP
2
BOLT CAP M6
1
HEX.KEY WRENCH 4MM
4
3
5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Easton KTS6057 and is the answer not in the manual?

Questions and answers

Summary of Contents for Courtyard Creations Easton KTS6057

  • Page 1 Children should always be under direct adult supervision while using the product. Retain the assembly instructions for future reference. Quote the following FQC NO. when contacting the service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 COURTYARD CREATIONS INC. PAGE 1 OF 2...
  • Page 2 FIGURE 2 FULL ASSEMBLY Step 2: Step 3: At the back of the chair, fasten the seat assembly See Full Assembly. (#1) to the base assembly (#2) by using bolts (#3) and washers (#4). See Figure 2. Make sure that all of the bolts have been tightened completely, and then cover them with plastic caps (#5) and bolt caps (#6).
