ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
!
Use the correct bolts as indicated. Do not tighten any of the bolts until the swing is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
RUS487W
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
STOP
DON'T RETURN TO STORE!
PAGE 1 OF 8
-WM
COURTYARD CREATIONS INC.
Advertisement
Table of Contents
Related Manuals for Courtyard Creations RUS487W-WM
Summary of Contents for Courtyard Creations RUS487W-WM
- Page 1 Children should always be under direct adult supervision while using this product. Retain these assembly instructions for future reference. Quote the following FQC NO. when contacting the service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 STOP DON’T RETURN TO STORE! PAGE 1 OF 8 COURTYARD CREATIONS INC.
- Page 2 A. Read the instructions thoroughly. Acquaint yourself with the inventory of parts and the accompanying drawings to ensure safe and proper assembly. B. You will need the following tools: - Phillips Screwdriver - Nut Wrench (See Part #37) - Hex. Key Wrench (See Part #38) C.
- Page 3 ASSEMBLY (Note: When fastening with nuts and bolts, always use a washer (#25, #26, or #27) between the tube and the bolt or the tube and the nut.) Step 2 Step 1 Step 1: Fasten the front and rear upright supports (#2 and #3) at the top by using bolts (#17), washers (#25), and steel nuts (#28).
- Page 4 Step 6: Slide the canopy/frame connectors (#32) onto Step 1 the canopy (#39). Fasten them together by using screws (#23). Make sure that the teeth of the canopy/frame connectors are facing towards the inside of the frame. See Fig. B – Step 1 and Step 2. Step 2 Fig.
- Page 5 Step 8: Step 1 Insert the seat arms (#6 and #7) into the front support brace (#8) and back support brace (#9). See Fig. D – Step 1 and Step 2. Note: Step 2 1. The labels marked “L” and “R” on the seat arms (#6 and #7) should coincide with Figure D - Step 1 to ensure proper assembly.
- Page 6 Step 12: Insert the table bottom braces (#13 and #14) Step 1 into the connector tabs located on the front support brace (#8). Fasten together with screws (#24). See Fig. E – Step 2. Fasten the table bottom braces (#13 and #14) to the back support brace (#9) by using bolts (#21) and washers (#26).
- Page 7 Step 15: Hook the suspension springs (#31) into the top of both holes of the swing arm tubes (#15). Repeat the same procedure for both sides. See Fig. H. Fig. H Step 16: Hang the opposite ends of the suspension springs (#31) into the holes located on the angled braces of the top cross beam w/adjustable teeth (#1).
- Page 8 STOP! Missing A Part? No Need To Go Back To The Store The store where you made your purchase does not stock parts for this item. If you need parts, whether they are missing or damaged, Call Toll Free: TEL: 1-877-539-7436 FAX: 1-877-539-7439 Call us between 9:00 AM and 4:30 PM Eastern Time Monday through Friday...
