Courtyard Creations KTS588X-WM Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
KTS588X-CS03-1
2
KTS588X-CS11-2
3
17C01A0714003Y4
4
17FA05040301-Y4

Step 1:

Fasten the back assembly (#1) to the seat
assembly (#2) by using bolts (#3), washers (#4)
and plastic nuts (#5). Make sure that all of the bolts
have been tightened completely and cover them
with bolt caps (#6). See Figure 1.
!
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
! Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
!
children. Children should always be under direct adult supervision while using this product.
! Retain these assembly instructions for future reference.
Quote the following FQC NO. when contacting the service center.
!
INTENDED FOR RESIDENTIAL USE ONLY.
KTS588X-
PART Q'TY
BACK ASSEMBLY
SEAT ASSEMBLY
BOLT M6*40
WASHER d6.5*D13*1.0
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 2
WM
PART
MATERIAL CODE
NO.
5
1
18000C23001
6
1
18000337002
2
7
17KAA0201----Y4
4 8
17KAB1101----Y4
FIGURE 1
