Analog Devices DC2881A-A Manual page 14

DEMO MANUAL DC2881A-A
PARTS LIST
ITEM QTY REFERENCE
29 1 R73
30 0 R88, R158
31 2 R69, R70
32 2 R128, R150
33 0 R139
34 1 R144
35 0 R159
36 1 R197
37 2 R210, R213
38 4 Q3, Q4, Q21, Q22
39 1 U3
40 1 U5
41 1 U6
Hardware: For Demo Board Only
1 25 E1, E2, E3, E4, E5, E6, E7, E8,
E10, E11, E12, E13, E14, E16,
E19, E20, E33, E34, E35, E36,
E37, E38, E39, E40, E41
2 6 J1, J2, J3, J4, J5, J6
3 3 J7, J8, J9
4 1 J13
5 1 J14
6 1 J15
7 1 J16
8 1 J25
9 3 JP1, JP7, JP9
10 1 JP6
11 8 JP12, JP13, JP14, JP15, JP16,
JP19, JP20, JP21
12 2 JP17, JP18
13 4 MP25, MP26, MP27, MP28
14 2 SW1, SW2
15 6 XJP1, XJP6, XJP7, XJP9, XJP19,
XJP20
14
PART DESCRIPTION
RES., 0.01Ω, 1%, 1W, 2512, PWR, METAL, SENSE,
AEC-Q200
RES., OPTION, 0805
RES., 10Ω, 1%, 1/10W, 0603
RES., 4.99k, 1%, 1/10W, 0603
RES., OPTION, 1206
RES., 15.8k, 1%, 1/10W, 0603, AEC-Q200
RES., OPTION, 2512
RES., 0Ω, JUMPER, 75A, 2010, COPPER, SENSE
RES., 0Ω, 1/8W, 0805
XSTR., MOSFET, P-CH, 30V, 3.3A, SOT-23-3
2
IC, EEPROM, I C, TSSOP-8, 2Kb (256 × 8), 400kHz
OSC., 3.81Hz to 1MHz, 5pF, 90ppm, TSOT23-6
IC, SINGLE R to R IN/OUT OP AMP , TSOT23-5,
100V/µs, 85MHz
TEST POINT, TURRET, 0.094" MTG. HOLE, PCB 0.062" THK
EVAL BOARD STUD HARDWARE SET, #10-32
CONN., RF , BNC, RCPT, JACK, 5-PIN, ST, THT, 50Ω
CONN., HDR, FEMALE, 2 × 7, 2mm, R/A THT
CONN., HDR, SHROUDED, MALE, 2 × 6, 2mm, VERT, ST, THT AMPHENOL, 98414-G06-12ULF
CONN., HDR, MALE, 2 × 7, 2mm, R/A THT
CONN., HDR, SHROUDED, MALE, 1 × 4, 2mm, VERT, ST, THT HIROSE ELECTRIC, DF3A-4P-2DSA
CONN., HDR, MALE, 2 × 6, 2.54mm, VERT, ST, THT, 30u" Au SAMTEC, TSW-106-07-S-D
CONN., HDR, MALE, 1 × 3, 2.54mm, VERT, ST, THT
CONN., HDR, MALE, 2 × 3, 2.54mm, VERT, ST, THT
CONN., HDR, MALE, 1 × 2, 2.54mm, VERT, ST, THT
CONN., HEADER, HDR, 2 POS, 2.54mm, ST THT
STANDOFF , NYLON, SNAP-ON, 0.625 (5/8"), 15.9mm
SWITCH, SLIDE, DPDT, 0.3A, 6VDC, PTH
CONN., SHUNT, FEMALE, 2 POS, 2.54mm
MANUFACTURER/PART NUMBER
VISHAY, WSL2512R0100FEA
VISHAY, CRCW060310R0FKEA
PANASONIC, ERJ3EKF4991V
NIC, NRC06F1582TRF
VISHAY, WSL201000000ZEA9
VISHAY, CRCW08050000Z0EA
DIODES INC., DMP3068L-13
MICROCHIP , 24LC024-I/ST
ANALOG DEVICES INC.,
LTC6992IS6-1#PBF
ANALOG DEVICES INC.,
LT1803IS5#PBF
MILL-MAX, 2501-2-00-80-00-00-07-0
ANALOG DEVICES INC., 720-0010
AMPHENOL RF , 112404
SULLINS CONNECTOR SOLUTIONS,
NPPN072FJFN-RC
MOLEX, 0877601416
SAMTEC, TSW-103-07-L-S
SAMTEC, TSW-103-07-L-D
WURTH ELEKTRONIK, 61300211121
SAMTEC, TSW-102-06-L-S
KEYSTONE, 8834
C&K, JS202011CQN
SAMTEC, SNT-100-BK-G
Rev. 0
