DEMO MANUAL DC2881A-A
PARTS LIST
ITEM QTY REFERENCE
24 2 Q7, Q8
25 1 Q9
26 1 R1
27 2 R2, R183
28 17 R3, R4, R5, R16, R167, R171,
R172, R177, R179, R184, R186,
R190, R191, R194, R195, R222,
R223
29 12 R6, R8, R10, R29, R30, R34,
R181, R182, R185, R187, R192,
R193
30 1 R9
31 3 R11, R12, R13
32 1 R82
33 1 R83
34 1 R84
35 2 R85, R200
36 1 R160
37 2 R161, R170
38 1 R162
39 1 R164
40 1 R166
41 1 R168
42 3 R169, R208, R209
43 1 R206
44 1 R207
45 2 R224, R225
46 1 U1
47 1 U2
48 1 U8
49 1 U9
12
PART DESCRIPTION
XSTR., MOSFET, N-CH, 60V, 220mA, SOT23-3, AEC-Q101
XSTR., MOSFET, N-CH, 30V, 90A, TO-252-3 (DPAK)
RES., 0.001Ω, 1%, 1W, 2512, METAL, SENSE, AEC-Q200
RES., 1Ω, 1%, 1/10W, 0603, AEC-Q200
RES., 0Ω, 1/10W, 0603, AEC-Q200
RES., 10k, 1%, 1/10W, 0603, AEC-Q200
RES., 4.99k, 1%, 1/10W, 0603
RES., 1k, 1%, 1/10W, 0603, AEC-Q200
RES., 10Ω, 1%, 1/10W, 0603
RES., 1.24M, 1%, 1/10W, 0603, AEC-Q200
RES., 402Ω, 1%, 1/4W, 1206, AEC-Q200
RES., 27.4Ω, 1%, 1W, 2512, AEC-Q200
RES., 2Ω, 1%, 1/10W, 0603
RES., 43.2k, 1%, 1/10W, 0603, AEC-Q200
RES., 60.4k, 1%, 1/10W, 0603, AEC-Q200
RES., 200k, 1%, 1/10W, 0603
RES., 84.5k, 1%, 1/10W, 0603, AEC-Q200
RES., 1Ω, 5%, 1/4W, 1206, AEC-Q200
RES., 619k, 1%, 1/10W, 0603, AEC-Q200
RES., 0Ω, 1/8W, 0805
RES., 931k, 1%, 1/10W, 0603, AEC-Q200
RES., 150Ω, 1%, 1/10W, 0603, AEC-Q200
IC, STEP-DOWN POWER CONTROLLER, GQFN-48
IC, DUAL MONOLITHIC DRIVER AND HALF BRIDGE,
LQFN-42
40V, 1A, 100µA I SYNCHRONOUS STEP-DOWN
Q
CONVERTER, MSE-16
IC, 3µA I , 20mA, 45V LOW, DROP OUT LINEAR
Q
REGULATOR, SOT-8
MANUFACTURER/PART NUMBER
DIODES INC., 2N7002A-13
INFINEON, IPD90N03S4L-02
VISHAY, WSL25121L000FEA
NIC, NRC06F1R00TRF
VISHAY, CRCW06030000Z0EA
PANASONIC, ERJ3EKF1002V
PANASONIC, ERJ3EKF4991V
VISHAY, CRCW06031K00FKEA
VISHAY, CRCW060310R0FKEA
VISHAY, CRCW06031M24FKEA
VISHAY, CRCW1206402RFKEA
PANASONIC, ERJ1TNF27R4U
VISHAY, CRCW06032R00FNEA
PANASONIC, ERJ3EKF4322V
VISHAY, CRCW060360K4FKEA
NIC, NRC06F2003TRF
NIC, NRC06F8452TRF
PANASONIC, ERJ8GEYJ1R0V
NIC, NRC06F6193TRF
VISHAY, CRCW08050000Z0EA
PANASONIC, ERJ3EKF9313V
PANASONIC, ERJ3EKF1500V
ANALOG DEVICES INC.,
LTC3884IRHE-1#PBF
ANALOG DEVICES INC.,
LTC7050AV#PBF
ANALOG DEVICES INC.,
LTC3646EMSE-1#PBF
ANALOG DEVICES INC.,
LT3008ETS8#PBF
