Haier HWM60-78 User Manual

Two-drive automatic washing machine
Hide thumbs

Advertisement

Quick Links

Specification
Model
Rated voltage frequency
Spinning capacity
6.0kg (weight of standard dry cloth)
1/18L 2/24L 3/29L 4/34L 5/38L
Water level/Water quantity (about)
6/42L 7/46L 8/50L 9/54L 10/59L
Max water consumption
About 90L(High water level; Normal program)
Injection pressure
Rated washing power
Rated spinning power
Weight
Dimension
HWM60-78
220-240V ~
50Hz
0.03MPa~0.78MPa
400W
265W
About 37kg
L 560 mm W 630mm H 890 mm
HWM60-78
Two-drive automatic washing machine
Please read this manual carefully before using.
Retain it for future reference.
Please check if the power receptacle has good earthing
condition before using to guarantee your safety.
The manufacturer will not take responsibility for those
risks occurred from not obeying this manual.
TWO-DRIVE
TWO 50% CONSUMPTION SAVER
CONTENTS
Names of the parts.............the 2nd cover
Safety precautions .............................................1
Installation and adjustment .........................3
before washing........................7
Put in the laundries ...........................................8
Usage of the detergent .....................................9
Use the operation buttons ...................10
Close the top lid .................................14
Finish washing ...................................14
Disposal after washing .........................15
Trouble shooting..............................16
Packing list.....................................17
Specification................the back cover

Advertisement

loading

  Also See for Haier HWM60-78

  Related Manuals for Haier HWM60-78

  Summary of Contents for Haier HWM60-78

  • Page 1: Table Of Contents

    Specification Model HWM60-78 Rated voltage frequency 220-240V ~ 50Hz Spinning capacity 6.0kg (weight of standard dry cloth) 1/18L 2/24L 3/29L 4/34L 5/38L Water level/Water quantity (about) 6/42L 7/46L 8/50L 9/54L 10/59L Max water consumption About 90L(High water level; Normal program) Injection pressure 0.03MPa~0.78MPa...
  • Page 2: Before Using

    Names of the par ts Round cover Attachment block (3 pieces) Pulsator Water inlet valve Water absorption cushion Cabinet handle Power cord Drain hose Back cover Adjustable leg film Accessories the end connecting to the washing machine Inner cover component (1 piece) Bottom plate (1 piece) Water inlet hose (1 piece) Water inlet hose joint (1 piece)
  • Page 3: Safety Precautions

    Trouble-shooting Answer to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
  • Page 4 Safety precautions Do not put hand into the rotating tub.It is dangerous Do not decompose, repair or alter the machine by even if the rotation speed is slow. Take special care of yourself. the children. Keep children away from the washing machine to avoid them climbing on.
  • Page 5: Installation And Adjustment

    * Total time: including the normal water inlet time and drain time. The total washing time may be influenced by the water inlet pressure and water level. * Spin time: From the moment the intermittent spinning starts to the moment it stops running (the time displayed on spin digitron is from intermittent spinning to the moment before inertia spinning;...
  • Page 6 Adjust the Installation position The washing machine away from wall should be overrun 20mm. The largest allowable slope of the shank base of the machine is 1 .The slanting or rough ground will result inunstable running or stoppage of the machine. Please adjust it with following methods: Confirm it's horizontal: Hang the lead line to check if it is...
  • Page 7: Install The Water Inlet Hose

    Steps of using the operation buttons and description of the steps WATER LEVEL RESERVE Push the "POWER ON/OFF " button to switch on the power. After switch on the power ,the machine will set have no disinfect function . If select the disinfect function.Push the rise/disinfect button .when the disinfect is indicating .please refer 2 to operating or refer 3 to operating.
  • Page 8 Connection between the water inlet hose and the washer 1.Do not take off the water absorption cushion. Please check if the nut of the water cushion is dropped or damaged before each usage. If it happens inlet hose please contact our after-sale department immediately.
  • Page 9: Using Process

    4 Use the operation buttons Description of the function of buttons Mode and meaning of the indicators Flashing: indicate the running program On: indicate the program about to run, or indicate the selected mode 60-78 SOAK Wash button Rinse/Disinfect button Soak button Push the soak button to set the Push the wash button to set...
  • Page 10: Usage Of The Detergent

    2 Put in the laundries The thickness ,size , type of the cloth will influence the actual washing capacity. It is suitable to put in reasonable amount of laundries and the laundries can be turned round in washing for one time washing. Do not select above "...

This manual is also suitable for:

Xqs60-78
