Replacement of the Oven Light Bulb
WARNING!
In order to avoid the possibility of an electric shock ensure that the appliance is
disconnected from the power supply before replacing the bulb.
Set all control knobs to the position"●"/"0" and
disconnect the mains plug
Unscrew and wash the lamp cover and then wipe
it dry
Unscrew the light bulb from the socket, replace
the bulb with a new one-a high temperature bulb
(300℃) with the following parameters:
-voltage230 V
-power 15 W
-thread E14.
Screw the bulb in, making sure it is properly
inserted into the ceramic socket.
Screw in the lamp cover.
Door Removal
In order to obtain easier access to the oven chamber
for cleaning, it is possible to remove the door. To do
this, tilt the safety catch part of the hinge upwards.
Close the door lightly, lift and pull it out towards you.
In order to fit the door back on to the a, do the reverse.
When fitting, ensure that the notch of the hinge is
correctly placed on the protrusion of the hinge holder.
After the door is fitted to the oven, the safety catch
should be carefully lowered down again. If the
safety catch is not set it may cause damage to the
hinge when closing the door.
Middle Layer Glass Removal
The oven door is made up of 3 panes of glass and has vents at the top and bottom. When the oven is operating,
air is circulated through the door to keep the outer pane cool. If condensation has worked its way in between the
glass panes, the door can be dismantled in order to clean in between the panes.
Remove the door as per above instruction and place it on a protective surface (e.g. on a table cloth) to prevent it
getting scratched. The door handle should line up with the edge of the table. Make sure the glass lies flat to avoid
breakage of glass during cleaning.
1. Undo the 2 screws on upper bracket.
2. Take out upper bracket and first pane of glass.
3. Loosen the 4 clips.
4. Slide out middle pane of glass carefully. Clean the glass panes and other parts with a damp microfiber cloth
or a clean sponge and a solution of hot water with a little washing-up liquid. Wipe dry using a soft cloth.
