60cm Built-In Ceramic
Cooktop
Installation and User manual
Content
Safety instructions-----------------------------------2
Features of your product---------------------------4
Installing the appliance-----------------------------4
Start using your appliance-------------------------7
Maintenance and troubleshooting---------------9
Warranty-----------------------------------------------10
the nearest authorised service centre
20130304 issue 8
BC604T
BC604T-F
BDC604OT
1
BDC604OT-F
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bellini BC604T
Summary of Contents for Bellini BC604T
-
Page 1: Table Of Contents
Features of your product---------------------------4 Installing the appliance-----------------------------4 Start using your appliance-------------------------7 Maintenance and troubleshooting---------------9 Warranty-----------------------------------------------10 For warranty service call 1300 373 199 (Australia) or 0508 123108 (New Zealand) to connect you to the nearest authorised service centre BC604T BC604T-F BDC604OT BDC604OT-F... -
Page 2: Safety Instructions
Safety Instructions This manual explains the proper installation and use of your appliance, please read it carefully before using even if you are familiar with the product. The manual should be kept in a safe place for future reference. In case of failure, all electrical work/repairs must be carried out by a suitable and authorised electrician or service agent, otherwise the guarantee will be null and void. - Page 3 Safety Instructions Safety When Cleaning with damaged bottoms can scratch the glass For cleaning, the appliance must be switched off ceramic if pushed across the surface. and cooled down. Objects that melt and things that boil over can For safety reasons, the cleaning of the burn onto the ceramic glass and should be appliance with steam jet or high pressure removed straightaway.
- Page 4 Features Of Your Cooktop Technical Data Product Dimensions Model (h x w x d) mm BC604T, BC604T-F 46x590x520 Electrical Max. Power Connection Rating 220-240V a.c 50Hz 6000 W Heating Elements Control Panel 1200 W Ø 140mm 1800 W Ø 180mm 1200 W Ø...
-
Page 5: Installing The Appliance
Installing The Appliance Important: There must be a minimum distance of 65mm from rear wall of cabinet Preparation Remove any dust from the benchtop directly surrounding the cut hole to ensure there is a clean surface. Remove the protective paper film from the adhesive strip that is secured to the bottom of the glass surface. - Page 6 Installing The Appliance Electrical Connection Caution: The appliance must only be installed and connected by a Licensed Electrician or Service Agent. If the mains supply where the cooktop is to be installed is different from 220...240V~,make the connection as shown in the enclosed diagrams. (The cable must be able to withstand temperatures of 120°C). Open terminal board cover at rear panel of appliance and connect as per below diagram for 220V –...
-
Page 7: Start Using Your Appliance
Start Using Your Appliance Control Panel of BC604T and BC604T-F Items Description Explanation Cooking zone selectors By pressing any of the 4 selector keys, the corresponding zone is selected for operation. The respective LED Display for that zone will flash for 6 Seconds on setting 9. - Page 8 Control Panel of BDC604OT and BDC604OT-F Items Description Explanation Power level From lowest level 1 to highest power display level 9. LED light turns ON at left-top of each power level display is telling which zone is under timer setting. Example as left Timer activated illustration is telling cooking zone 2a indication light...
- Page 9 Timer display It countdown when timer set to tell how many minutes working time left. Power level/ Press key 1 to 4 to choose cooking Timer adjustor zone, then press + or – when display is flashing to choose desired power level. If you want to set up timer, then press Timer key when display is flashing to enter into Timer setting.
- Page 10 Start Using Your Appliance Selecting The Correct Pan Choose a pan with a diameter that is at least as large as the heating zone. Do not use pans with a concave, convex or a rough base, ensure to select flat bottom pans . Always remember to put the correct lid on the pan.
-
Page 11: Maintenance And Troubleshooting
Maintenance & Troubleshooting Caution: Spills and splashes will not harden and stick to the glass, as it hardly heats up. Vitro-ceramic should however be cleaned of any spills or splashes as quickly as possible. Slight stains can be removed with kitchen paper or cloth. More resistant stains will need specific product for vitro-ceramic glass. -
Page 12: Warranty
Consumer until the expiry of two (2) years (Warranty Period). If within the Warranty Period a manufacturing defect is discovered in the Bellini product or it fails to perform to the Company’s specifications as a result of some defect in materials, components or workmanship (Defect) then the Company will, at its option, repair the Bellini product or supply a replacement Bellini product free of charge. -
Page 13: For Warranty Service Call 1300 373 199 (Australia)
1.10 If you are required to transport the Bellini product to the Company or its service agent, you must ensure it is safely disconnected by a qualified tradesman and securely packed and insured. The Company does not accept any responsibility for loss or damage of the Bellini product prior to it being received by the Company or its service agent.
