Bellini BDG604G Installation And User Manual

Black glass top-surface built-in gas cooktop

Hide thumbs Also See for BDG604G:

Installation & operation instructions (17 pages)

Quick Links

啊哈

Black Glass Top-surface

Built-in Gas Cooktop

Installation and User manual

Content

Safety instructions---------------------------------- 2

Product description--------------------------------- 4

Installation---------------------------------------------6

Start using your appliance--------------------------10

Maintenance and troubleshooting----------------12

Warranty------------------------------------------------ 14

For warranty service call 1300 373 199(Australia)

or 0508 123108(New Zealand) to connect you to

the nearest authorised service centre

BDG604G, BDG604G-F, BDG604GA, BDG604GA-F

BDG302WG, BDG302WG-F, BDG302WGA, BDG302WGA-F

BDG302RG, BDG302RG-F, BDG302RGA, BDG302RGA-F

BDG301G, BDG301G-F, BDG301GA, BDG301GA-F

20130114 issue 2

Need help?

Do you have a question about the BDG604G and is the answer not in the manual?

Questions and answers

Summary of Contents for Bellini BDG604G

Page 1: Table Of Contents
Maintenance and troubleshooting----------------12 Warranty------------------------------------------------ 14 For warranty service call 1300 373 199(Australia) or 0508 123108(New Zealand) to connect you to the nearest authorised service centre BDG604G, BDG604G-F, BDG604GA, BDG604GA-F BDG302WG, BDG302WG-F, BDG302WGA, BDG302WGA-F BDG302RG, BDG302RG-F, BDG302RGA, BDG302RGA-F BDG301G, BDG301G-F, BDG301GA, BDG301GA-F...
Page 2: Safety Instructions
Safety Instructions This manual explains the proper installation and use of your appliance, please read it carefully before using even if you are familiar with the product. The manual should be kept in a safe place for future reference. In case of failure, only the Authorized Technical Service may repair this hob.
Page 3 diameter and no more than 1.0metre in length. Safety Instructions Any hose assembly used must be restrained Safety When Installation from accidental contact with the flue outlet of an Do not use or store flammable materials in the under bench oven. appliance storage drawer or near this appliance.
Page 4: Product Description
Burner Product Description BDG604GA, BDG604GA-F *BDG604G, *BDG604G-F * have no aluminum trim Trivet Aluminum trim Control knobs BDG302W/RGA, BDG302W/RGA-F BDG301GA,BDG301GA-F *BDG302W/RG, *BDG302W/RG-F, *BDG301G,*BDG301G-F, * have no aluminum trim * have no aluminum trim Burner Trivet Aluminum trim Control knobs...
Page 5 1 set attach it onto a surface where it can be read e.g. inside labels surface of adjacent cupboard Installation 4 sets clip Screws 4 for BDG604G/A(-F), 3 for ST4.2x24 BDG302*G/A(-F)&BDG301G/A(-F) 0.55mmx1, 0.7mmx2, BDG604G/A(-F) 0.98mmx1 LPG Injectors BDG302WG/A(-F) 0.7mmx1, 0.98mmx1 BDG302RG/A(-F) 0.7mmx1, 0.9mmx1...
Page 6: Installation
TO BE INSTALLED ONLY BY AN AUTHORIZED PERSON. 1. Cupboard Cutting Bench top thickness, 30– 40 mm (3 – 4 cm). BDG604G(A)/BDG604G(A)-F BDG302WG(A)/BDG302WG(A)-F/BDG302RG(A) BDG302RG(A)-F/ BDG301G(A)/ BDG301G(A)-F...
Page 7 2. Place Burner Box Apply the adhesive sealing tape to the underside lip of the burner box. Shown at G opposite. Place burner box into cutout hole and fit clamping brackets to clamp the hotplate to the bench. 3. Fit Burners And Trivet. Replace burners and ensure they are correctly repositioned over the ignitor (S) and thermocouple (T).
Page 8 75oC at any point along its length. After having installed the hotplate, the GPO must always be in an accessible position. Wiring diagram for Wiring diagram for BDG604G/A(-F) BDG302*G/A(-F) Wiring diagram for BDG301G/A(-F) 4. Gas Connection Install in accordance with relevant gas standards and/or codes of practice applicable.
Page 9 The manufacturers servicing instructions detail how authorised personnel may convert the hotplate from Natural gas to Universal LPG or from Universal LPG to Natural gas. Contact the manufacturer or agent as required. Model NATURAL GAS UNIVERSAL LPG BDG604G/A(-F) Injector Dia(mm) MJ/h Test point kPa Injector Dia(mm)
Page 10: Start Using Your Appliance
Start Using Your Appliance Description Explanation These show which zone is under control. Zone indicators Flame power Flame power of the zones, is the lowest and is the highest. The hotplates are fitted with mains powered electronic spark ignitors, so must be connected to mains power supply (i.e.
Page 11 BURNER AND UTENSIL CHOICE Depending on the hotplate model, the burner choices are: BDG604G/A(-F): Auxiliary (small), Semi-Rapid x2 (medium), and Wok (triple ring) burners. BDG302WG/A(-F): Semi-Rapid (medium), Wok (triple ring) BDG302RG/A(-F): Semi-Rapid (medium), Rapid (large) BDG301G/A(-F): Wok (triple ring) The maximum utensil (pan) diameters in millimetres...
Page 12: Maintenance And Troubleshooting
Maintenance & Troubleshooting Cleaning and maintenance should be carried out with the appliance cold especially when cleaning the Use a cotton bud, tooth brush, or some other item to enameled parts. Avoid leaving alkaline or acid clean out any incrustations or dirt from the four holes substances(lemon juice, vinegar etc.) on the surfaces.
Page 13 TROUBLESHOOTING Servicing of the hotplates must only be done by an authorised service representative (see back of this booklet) and the hotplate must not be modified. Power must be disconnected before any servicing or maintenance is conducted. It is recommended the hotplate serviced by an authorized person at least every 2 years. This service is not covered by warranty.
Page 14: Warranty
Consumer until the expiry of one (1) year (Warranty Period). If within the Warranty Period a manufacturing defect is discovered in the Bellini product or it fails to perform to the Company’s specifications as a result of some defect in materials, components or workmanship (Defect) then the Company will, at its option, repair the Bellini product or supply a replacement Bellini product free of charge.
Page 15: For Warranty Service Call 1300 373 199(Australia)
1.10 If you are required to transport the Bellini product to the Company or its service agent, you must ensure it is safely disconnected by a qualified tradesman and securely packed and insured. The Company does not accept any responsibility for loss or damage of the Bellini product prior to it being received by the Company or its service agent.

This manual is also suitable for:

Bdg604g-f Bdg604ga Bdg604ga-f Bdg302wg Bdg302wg-f Bdg302wga ... Show all
