Lightspeed Topcat Registration Manual page 3

STANDARD REGISTRATION
REPLACING A FLEXMIKE (NO OTHER REGISTRED COPONENTS IN PLACE)
For users replacing a lost or malfunctioning Flexmike.
1. If replacing a Flexmike, make sure the malfunctioning unit is powered off.
2. Power on the new Flexmike. Both microphone 1 and 2 blue lights should
start blinking.
3. Open the Flexmike battery compartmentand pull the battery out
(leaving it plugged) to reveal the registration button.
4. Open the speaker panel of the Topcat (see Topcat Install Guide for instructions on how to open the panel). The Topcat can remain
installed for this process.
5. Using a paperclip, briefly press the registration button on the inside of the Topcat. The 1 and 2 lights will begin blinking on the
Topcat.
6. Briefly press the registration button on the Flexmike. The 1 and 2 lights will start blinking alternately.
TONE
TREBLE
BASS
MICROPHONE
MIN
MAX
7. After several seconds, the #1 light on the Topcat will turn solid and the #1
light on Flexmike will remain blinking, then turn solid.
8. The registration is complete. You can begin speaking into the new
Flexmike to verify there is audio.
9. Place system ID number (located in back of Topcat User Manual) on the new
Flexmike.
NOTE: if at any point, the Topcat or Flexmike lights begin blinking rapidly. that
indicates registration error. Turn the new Sharemike off and repeat steps 4-9.
MIN MAX
PAGEFIRST
SENSITIVITY
AUDIO IN
MIN
MAX
REGISTER
Blinking lights
Power On
(NEW Flexmike)
Blinking lights
Solid lights
Registration
Button
