NTI 3G-SDI to USB 3.0 Video Capture
CONNECTORS
#
LABEL
CONNECTOR
1
SDI IN
BNC Connector
2
HDMI OUT
HDMI female connector
3
USB 3.0
USB Type A Female
4
MICROPHONE
3.5mm Jack
5
HEADPHONES
3.5mm Jack
DESCRIPTION
for connection of incoming SDI video signal
for connection of HDMI display device
for connection of recording device
for connect of microphone
for connection of headphones
3
