Saxby Lighting Axial Rectangular Instruction Manual

Wiring
Having correctly identified the wiring from your existing light fitting, pull the mains wire through the hole and connect
to the connection block inside the LED driver in the following way:
This unit is double insulated and must not be earthed. If there are any incoming earth cables, they must be joined together
and well insulated with good quality insulation tape. This is to ensure earth continuity throughout your property.
SUPPLY
NEUTRAL
SWITCHED LIVE
Technical data
Supply
220-240 V~, 50 Hz
Voltage:
Bulb 35W LED module (COB), 4000K
Type:
This product contains a light source of energy efficiency class F.
Non-replaceable light source
Conformity with all relevant UKCA Directive requirements.
Conformity with all relevant EC Directive requirements.
The power supply is Double Insulated and does not require connection to an Earth circuit.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is not suitable for dimming.
Care and Safety
We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish.
For your safety, always switch off the power supply before cleaning.
This LED's are protected by a shade. The shade part must be replaced immediately should
it become cracked or damaged. This fitting must not be used without the shade in place.
Replace Cracked Shade
For further information, please visit https://www.lighting-info.co.uk/78542
V2 10/06/2022
UK Manufacturer: BH17 7BY
EU Manufacturer: Brilliant AG,
Brilliantstrasse 1, D-27442 Gnarrenburg
LIGHT FITTING
Check that...
BLUE (N) • You have correctly identified the wires.
• The connections are tight.
• No loose strands have been left out of the
BROWN (L)
connection block.
Replaceable control gear by a
professional
Instruction manual
Axial Rectangular
78542
