SERVICE MANUAL
［ IMPORTANT ］
▶ Please read the manual carefully and keep it in mind before using this machine
▶ Put this manual within touch of your reference in anytime.
ISSUE DATE:Apr. 13, 2022
PRODUCT INFO
PART INFO
SUPPORT INFO
NEW PRODUCT INFO
※ QR(SUPPROT) - Leaflets, manuals, solution(error code,trouble shooting decument, watch&solve)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bobblehead BASEBALL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Andamiro Bobblehead BASEBALL

Summary of Contents for Andamiro Bobblehead BASEBALL

  • Page 1 SERVICE MANUAL ［ IMPORTANT ］ ▶ Please read the manual carefully and keep it in mind before using this machine ▶ Put this manual within touch of your reference in anytime. ISSUE DATE:Apr. 13, 2022 PRODUCT INFO PART INFO SUPPORT INFO NEW PRODUCT INFO ※...
  • Page 2 The following safety precautions are given throughout this manual. They must be strictly followed to protect those who install, use or maintain this product as well as to protect players, visitors and property. For safty reasons. Disregarding could result in serious injury. Disregarding could result in injury or product damage.
  • Page 3 y r t l a i t s i i t t i r i i h t i f i a r t i t r . t c a t l e r i . s t , d r e i f i t a .
  • Page 4 t f I y t i r t s l a i l l e t t i d i s l a i t d i s l a i t e f f i t p and e v e l i s i , s t...
  • Page 5 i t i o i t . t c i t c n i t p i t . r e , s t s t r c i f i t a s t r i f i l l a l a i t s i c i r...

  • Page 10: Table Of Contents

    CONTENTS SPECIFICATION AND DIMENSION PAGE DIMENSION ……………………………………………………………………………… P02 SPECIFICATION ……………………………………………………………………………… P02 STICKER LOCATION ……………………………………………………………………………… P03 INSTALL INFORMATION INSTALLATION SPACE,KEEP THE PRODUCT HORIZONTAL ……………………………… P04 UNPACKING PACKING LOCATION ……………………………………………………………………………… P04 COMPONENTS ……………………………………………………………………………… P05 INSTALL HOW TO INSTALL(BILLBOARD)……………………………………………………………………………… P06 SETUP SETTINGS 1 ) SETUP BUTTON LAYOUT, 2) MACHINE SETUP, 3) TEST MODE ………………………………………… P07 4) TEST MODE - I/O TEST, 5) TEST MODE - SCREEN TEST …………………………………………...

  • Page 11: Specification And Dimension Page

    SPECIFICATION AND DIMENSION DIMENSION SPECIFICATION ITEM DETAILS VOLTAGE AC 120V AC 230V FREQUENCY RANGE 60 Hz 50/60 Hz CONSUMPTION INSTALL DIMENSION( W*D*H) 960*1644*1226mm , 378*647*483 inch PACKING DIMENSION(W*D*H) 960*1644*1226mm , 378*647*483 inch WEIGHT(kg), packing weight(kg) 250 kg, 270kg CERTIFICATION ※NOTE :NOTE : This product is a free bolt product.( AC 120-230V ) - 2 -...

  • Page 12: Sticker Location

    STICKER LOCATION ▼ 1 ▼ 2 ▼ 3 ▼ 4 ▼ 5 ▼ 6 Certification Label - 3 -...

  • Page 13: Install Information

    INSTALL INFORMATION INSTALLATION SPACE ※ Maintenance zone & Play zone should have at least 1200 mm(47 inch) * 1700mm(67inch) each MAINTAIN PRODUCT FLATNESS After installation is complete ※ ※ 2-1 After securing space, adjust the 4 adjuster so that the product is stably leveled. IMPORTANCE 1700mm 1200mm...

  • Page 14: Components

    COMPONENTS PART NAME Q'TY SPARE AC CORD MANUAL ERROR COED RENCH 2.5, 3, 4, 5 MM 1 EACH SCREW - TH_NI M4x8L SCREW - TH_NI M6x25L ▼ 1 ▼ 2 ▼ 3 ▼ 4 ▼ 5 ▼ 6, 7 ▼ 8 ▼...

  • Page 15: Install

    INSTALL HOW TO INSTALL PROCESS ITEM Q'ty BOLT SPEC Q'ty NOTE ASSEMBLE BILLBOARD REAR ACRYL TH_NI 4x12 BILLBOARD SIDE BKT - L, R FLANGE NUT ASSEMBLE BILLBOARD FRONT ACRYL TH_NI ASSEMBLE BILLBOARD ASS'Y SEMS 4x12 ▼ ▼ ▼ - 6 -...

  • Page 16: Setup Settings

    SETUP SETTINGS ▼ 1) ▼ 2) ▼ 3) SETUP BUTTON LAYOUT MODE NOTE SET-UP / UP Setup menu mode, menu up move SERVICE / SELECT Normally service in, select and perform - / DOWN Menu down move POWER Power off/on switch VOLUME Volume control MACHINE SETUP...
  • Page 17 ▼ 4) ▼ 5) TEST MODE - I/O TEST MODE NOTE CENTER BUTTON Game buton(Center) test: button press - on LEFT BUTTON Game button(Left) test: button press - on RIGHT BUTTON Game button(Right) test: button press - on TICKET BUTTON Ticket dispenser button: button press - on SERVICE BUTTON Setup button test: button press - on...
  • Page 18 ▼ 6) ▼ 7) ▼ 8) GAME SETTING MODE NOTE DEFAULT RANGE GAME LEVEL Select: Easy - Nomal - Hard Nomal GRANDSLAM INIT COUNT Set the initial starting number of "GRAND SLAM" values 0 ~ 6 1000 ~ INITIAL HIGH SCORE Initial high score setting, 100 unit increments 1500 2000...
  • Page 19 ▼ 9) ▼ 10) ▼ 11) SOUND SETTING MODE NOTE DEFAULT RANGE GAME VOLUME Game sound adjustment. 5 unit increments 0 ~ 100 DEMO VOLUME Demo sound adjustment. 5 unit increments 0 ~ 100 SOUND TEST Sound on. Off: sound reproduction for testing DEFAULT SETTING Set as default SAVE &...

  • Page 20: Statistics - Single Mode

    ▼ 12) STATISTICS - SINGLE MODE MODE NOTE TOTAL PLAY TIME The accumulated time from the start of the game to the end of the game AVERAGE PLAY TIME Average game time TOTAL PLAY COUNT Accumulated play count TOTAL TICKET OUT The number of tickets accumulated through the game AVERAGE TICKET OUT Average number of tickets obtained per game...

  • Page 21: Solution

    SOLUTION ▶ ERROR CODES BOBBLEHEAD BASEBALL CODE ERROR NOTE PAGE E.02 SYSTEM Error of reading/writing on setup data E.03 SYSTEM Setup data error E.11 COIN SELECTOR Error of sensor from coin selector E.12 BILL ACCEPTOR Error of sensor from bill acceptor COMMUNICATION ON E.21...

  • Page 22: Troubleshooting

    ▶ TROUBLESHOOTING 1) SYSTEM DATA ERROR ( E.02 , E.03 ) ERROR OR LOCATION ▶SOLUTION 1 HOW TO TEST POWER OFF → ON TEST 2 CHECK LIST 1) After turning the power off and on, check if the symptom appears. 2) ANDROID PCB REPLACEMENT ( P1 ) PART NAME CODE...
  • Page 23 2) I/O CONNECTION ERROR ( E.21 ) ERROR OR LOCATION G N D + 12V G N D G N D + 5V +12V + 12V +12V G N D + 5V ▶SOLUTION 1 TEST POWER OFF - ON TEST 2 CHECK : ANDROID 1) Check and reconnect the D-SUB 9PIN connector ( P1-1 )
  • Page 24 3) COMMUNICATION PROTOCOL ERROR ( E.22 ) / CODE CONNECTION ERROR ( E.23 ) ERROR OR LOCATION ▶SOLUTION 1 TEST POWER OFF - ON TEST 2 CHECK : 1) After turning the power off and on, check if the symptom appears. 2) BHB I/O replacement ( P9 ) PART NAME CODE...
  • Page 25 4) MONITOR ERROR ( NO SIGNAL ) ERROR OR LOCATION ▶SOLUTION 1 TEST POWER ON TEST 2 CHECK : When nothing is displayed on the MONITOR screen 1) After opening the door on the back of the product, check the power cable connected to the top of the monitor and reconnect it.

  • Page 26: Exploded View

    EXPLODED VIEW ▶ FULL DESCRIPTION PART NAME Q'TY PAGE PART NAME Q'TY PAGE BILLBOARD PART POWER SMPS BOX PART MONITOR PART CARD DISPENSER(OPTION) SPEAKER PART COIN SELECTOR(OPTION TABLE PANEL PART TICKET DISPENSER(OPTION) CONTROLLER PART MEI ACCEPTOR RELAY(OPTION) SETUP PANEL PART CARD OUTLET GUIDE(OPTION) MAIN PCB PART BILL ACCEPT(OPTION)

  • Page 27: Detailed Explanation

    ▶ DETAILED EXPLANATION BILLBOARD PART PART NAME SPEC. Q'TY CODE NO. BILLBOARD FRONT ACRYL ABHB0ACP006 12V LED BAR 460MM AZZZ0PCB124 BILLBOARD REAR ACRYL ABHB0ACP007 MONITOR PART PART NAME SPEC. Q'TY CODE NO. MONITOR 55INCH MZZZ0LED002 - 18 -...
  • Page 28 SPEAKER PART PART NAME SPEC. Q'TY CODE NO. SPEAKER COVER MESH PLATE PET 1.5t MSBT0ACR038 SPEAKER MID4.5"+TW1/2" 8OHM MZZZ0SPE021 - 19 -...
  • Page 29 TABLE PANEL PART PART NAME SPEC. Q'TY CODE NO. CONTROLLER CONTROLLER SIDE ACRYL - L ACRYL 3t ABHB0ACP004 CONTROLLER SIDE ACRYL - R ACRYL 3t ABHB0ACP005 TABLE CONVER BKT MBHB0MEP054 12V LED BAR 460MM AZZZ0PCB124 CONTROLLER FRAME FIX CENTER BKT CONTROLLER PLATE FIX BKT FRONT TABLE LED COVER BKT FRONT TABLE LED ACRYL...
  • Page 30 CONTROLLER PART PART NAME SPEC. Q'TY CODE NO. ASS'Y-CENTER BUTTON CONTROLLER CENTER BUTTON LED CENTER BUTTON SUP PET MBHB0ACR004 BUTTON ASS'Y CWB 401 MZZZ0BUT080 BUTTON WHEEL ASS'Y BUTTON CENTER FIX BKT - 21 -...
  • Page 31 SETUP PABEL PART PART NAME SPEC. Q'TY CODE NO. COUNTER OA127CL W/2P MZZZ0COU002 PUSH BUTTON SWITCH DS412R MELE0PUS006 ROCKER SWITCH R595KDF MELE0SWI021 VOLUME KNOB CAP BLUE MELE0VOL007 SETUP PANEL MBHB0MEP050 BOLUME PCB AHM20PCB016 SETUP PANEL COVER - 22 -...
  • Page 32 MAIN PCB PART PART NAME SPEC. Q'TY CODE NO. VIDEO IO BOARAD PCB ABHB0PCB001 MAIN BOARD IO PCB ABHB0PCB002 IO PCB AZZZ0PCB 185 POWER SMPS BOX PART PART NAME SPEC. Q'TY CODE NO. NOISE FILTER RNS-2010 MELE0NOI009 TERMINAL BLOCK 250V 10P UL_CE MELE0TEB003 POWER SMPS LRS-150F-12...

  • Page 33: Pcb Connetcor Location

    PCB CONNETCOR LOCATION ※ The arrow point means the contact pin number 1. pin description 1. The arrow point means the contact pin number 1. 2. direction of hirose connector 1) BHB IO PCB ASS'Y FUNCTION LOCATION POWER 12V, 5V COIN SPEAKER POWER 12V CN13...

  • Page 34: Ws2813B Io Pcb Ass'y

    3) WS2813B IO PCB ASS'Y FUNCTION LOCATION PIN LED - SIDE LEFT LED1 LED - SIDE RIGHT LED2 LED - CONTROL LED3 POWER 5V POWER RS232(MAIN PCB) JP10 - 25 -...
  • Page 35 [CN7] S E T U P S E T U P S E T U P S E T U P D - S U B UART0 20-01 2 _ R X D C O M 1 T X 0 09-01 08-01 3 _ T X D...
  • Page 36 C E N T E R 10-02 B U T T O N [CN5] [CN9] C O I N 1 P BTN_LAMP COIN 14-01 15-01 10-01 1 2 V I N H I B I T 1 L A M P 1 C O I N 1 L A M P 2 G N D...
  • Page 37 BILLBOARD LED 4 6 0 m m B A R L E D ( W H I T E ) 4 6 0 m m B A R L E D ( W H I T E ) 07-01 B I L L B O A R D L E D J O I N P A G E 1 / 3 B O B B L E H E A D B A S E B A L L...
  • Page 38 Andamiro warrants the parts from date of shipment as follows. Andamiro warrants the parts from date of shipment as follows. - One Year Limited Warranty : Electronic Boards & Monitor - One Year Limited Warranty : Electronic Boards & Monitor...
