Precautions for use
The following safety precautions are given throughout this manual. They must
be strictly followed to protect those who install, use or maintain this product as
well as to prevent other
people's injuries and property damages.
• The following suggestions show the degree of danger and damage caused
WARNING
Indicates a situation where disregarding the suggestions could result in death or serious injury.
WARNING
CAUTION
Indicates a situation where disregarding the suggestions could result in injury or product damage.
CAUTION
• The following graphic suggestions describe the types of precautions to be followed.
Indicates a matter of which care should be taken.
Indicates a matter which should be performed without fail.
• The following graphic suggestions describe the types of precautions to be followed.
In this instruction manual, some procedures require a qualified in-shop maintenance person or
industry specialist. For such instructions, a qualified person must take care of the jobs.
• Otherwise an electric shock, machine trouble, or a serious accident may result.
• Replacing the machine parts, inspecting and maintaining the machines, and troubleshooting must be
assigned only to a qualified in-shop maintenance person or industry specialist. This booklet gives
instructions that hazardous jobs in particular must be handled by an industry specialist. Qualified in-shop
maintenance persons and industry specialist are defined as follows.
Qualified in-shop maintenance persons
• A qualified in-shop maintenance person must have experience in maintaining amusement machines. Under
the supervision of an amusement machines shop owner or manager, he or she routinely assembles, installs,
inspects and maintains the amusement machines, or replaces their component units and consumable parts,
in the amusement machines workshop and/or location.
Jobs handled by qualified in-shop maintenance persons
•Assembling, installing, inspecting and maintaining amusement machines and replacing their component units
and consumable parts.
Industry specialist
•An industry specialist must be engaged in designing, manufacturing, inspecting and servicing amusement
machines. Or he or she must have an education in electrical, electronic and mechanical engineering, and
routinely maintain and repair amusement machines.
Jobs handled by industry specialist
•Assembling and installing amusement machines and repairing and adjusting their electrical, electronic and
mechanical component parts.
Be sure to read the following
Indicates a matter which is forbidden.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Joy-Ro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Andamiro Joy-Ro

  • Page 1 Precautions for use The following safety precautions are given throughout this manual. They must be strictly followed to protect those who install, use or maintain this product as well as to prevent other Be sure to read the following people's injuries and property damages. •...
  • Page 2 Setting Up WARNING CAUTION Be sure to consult your nearest dealer when Be sure to use indoor wiring for within the setting up, moving or transporting this product. specified voltage range. For extension cord, • This product should not be set up, moved or use indoor wiring of the specified rating or transported by any one other than an industry more.
  • Page 3 • Otherwise an accident or electric shock may casters. result. Never allow anyone else but • Otherwise, an accident, breakage or trouble ANDAMIRO's service engineers to open the may result. upper door on the back of the machine. Do not apply a strong force for moving the If the sub power switch of the service panel is machine.
  • Page 4: Name Of Each Part

    1. NAME OF EACH PART 1-1) NAME OF EACH P A RT S P E A K E R BILLBOARD P A N E L FRONT CASE C RT ( 2 5 ” ~ 2 9” ) MONITOR MASK BUTTON P A N E L BACK CASE SIDE COVER FRONT DOOR...
  • Page 5: Power Supply Unit

    2-3) COIN COUNTER & POWER SUPPLY UNIT POWER SUPPLY UNIT GAME BOARD COIN COUNTER ◎ If COIN COUNTER and GAME BOARD are disconnected electrically, STOP game operation does not function. IMPORTANT ◎ COIN COUNTER is located under the COIN BOX and counts number of coin to be i n p u t t e d .
  • Page 6 3. NOTICES IN TREATMENT 3-1) NOTICES IN TREA T M E N T - When installing or checking machine, you must follow the following notices to enable users to enjoy game safely. ◎ Check the usage voltage, and then turn on the power button. ◎...
  • Page 7 4-2) INSTA L L AT I O N Acceptable maximum current of this machine is 10A with outlet. You can connect up to 6 devices. When you connect 7 devices or more, it is prohibited strictly because the current is higher than 10A of the W A R N I N G designated current, it is very 4-3) MACHINE...
  • Page 8: Parts Name

    5. ASSEMBLY DIAGRAM AND PART LIST 5-1) CRT SETTING ASS’ Y N O . PA R TS NAME S P E C Q t y . CODE NO. CRT SUPPORT PIN M 1 0 x 5 2 L M 0 3 0 0 9 - 0 0 6 A S E M S M 6 x 1 6 L M 1 4 0 0 9 - 0 2 7 A...
  • Page 9 Assemble E on F and check whether CRT position D(MONITOR MASK part of FRONT CASE) and E is suitable. If you change position of CRT, disassemble E in F, loosen flush BOLT of G, and adjust the position by moving F up and down.
  • Page 10 5-4) AC BOX ASS’ Y N O . PA R TS NAME S P E C Q t y . CODE NO. ROCKER SWITCH T - 1 2 0 A 0 4 0 0 4 - 0 0 1 A AC BOX C 0 3 0 0 9 - 0 2 6 A AC POWER CORD...
  • Page 11 5-6) COIN BOX ASS’ Y N O . PA R TS NAME S P E C Q t y . CODE NO. COIN BOX CASE C 0 3 0 0 9 - 0 2 5 A COIN BOX COVER M 0 2 0 0 9 - 0 2 2 A COIN GUIDE C 0 3 0 0 9 - 0 3 1 A COIN GUIDE SUPPORT-L...
  • Page 12 5-8) DOOR FRAME ASS’ Y N O . PA R TS NAME S P E C Q t y . CODE NO. CORNER CASE C 0 3 0 0 9 - 0 2 1 A M5 BOLT WASHER M 0 2 0 0 9 - 0 5 1 A WASHER BASED BOLT M 5×1 0 L M 1 4 0 1 5 - 0 1 8 A...
  • Page 13 5-9) SIDE CASE & M O N I TOR SETTING PLATE ASS’ Y N O . PA R TS NAME S P E C Q t y . CODE NO. MONITOR SETTING PLATE-L C 0 3 0 1 0 - 0 0 9 A MONITOR SETTING PLATE-R C 0 3 0 1 0 - 0 1 0 A SIDE COVER-L...
  • Page 14 5 - 11) MAIN BOARD GUIDE ASS ’ Y N O . PA R TS NAME S P E C Q t y . CODE NO. MAIN BOARD PANEL C 0 3 0 0 9 - 0 2 2 A COIN BOX C 0 3 0 0 9 - 0 3 8 A MAIN BOARD GUIDE...
  • Page 15 5-13) CASE, COIN DOOR ASS ’ Y N O . PA R TS NAME S P E C Q t y . CODE NO. MAIN PCB BURGLARPROOF LOCK M 0 2 0 0 9 - 0 4 5 A WASHER BASED BOLT M 4×1 0 L M 1 4 0 1 5 - 0 1 1 A...
  • Page 16 5-15) BUTTON CASE ASS’ Y N O . PA R TS NAME S P E C Q t y . CODE NO. COIN COVER M 0 2 0 1 0 - 0 0 1 A A S H T R A Y M 0 2 0 0 9 - 0 1 8 A UPPER BUTTON CASE C 0 3 0 1 0 - 0 0 5 A...
  • Page 17 5-17) REAR TOP CASE ASS’ Y N O . PA R TS NAME Q t y . S P E C CODE NO. TOP CASE REAR DOOR C 0 3 0 1 0 - 0 1 8 A REAR TOP CASE C 0 3 0 1 0 - 0 1 1 A LAMP SOCKET BRACKET M 0 2 0 1 0 - 0 2 2 A...
  • Page 18 5-19) LAMP SOCKET ASS’ Y N O . PA R TS NAME S P E C Q t y . CODE NO. TOP SIDE CASE-L C 0 3 0 1 0 - 0 1 3 A TOP SIDE CASE-R C 0 3 0 1 0 - 0 1 4 A LAMP SOCKET-L C 0 3 0 1 0 - 0 2 4 A LAMP SOCKET-R...
  • Page 19 5-21) FRONT CASE AND MONITOR MASK ASS ’ Y 1. ⒶThese parts are LED OPTIONS to display number of CREDIT and COIN in participating in GAME. They are OPTIONS to change in SERVICE S/W and KEY. N O . P A R TS NAME S P E C Q t y .
  • Page 20 5-23) MONITOR FRONT FRAME ASS ’ Y N O . PA R TS NAME S P E C Q t y . CODE NO. MONITOR FRONT FRAME M 0 2 0 1 0 - 0 1 0 A CRT ADJUST GEAR C 0 3 0 0 9 - 0 4 0 A CRT FRAME SETTING-L M 0 2 0 1 0 - 0 2 0 A...
  • Page 21: Solder Side

    7. JAMMA CONNECTOR SOLDER SIDE P A R TS SIDE B l a c k G N D G N D B l a c k B l a c k G N D G N D B l a c k R e d + 5 V + 5 V...
  • Page 22: Wiring Iagram

    8. WIRING IAGRAM 8-1) TO TAL HARNESS B K = B L A C K BKW=BLACK WHITE B N = B R O W N BNW=BROWN WHITE R D = R E D RDW=RED WHITE O E = O R A N G E OEB=ORANGE BLACK Y W = Y E L L O W YWB=YELLOW BLACK...
  • Page 23 8-2) STEREO AMP & SPEAKER SPECIFICA T I O N VOLUME CONTROL ◎ When MAIN PCB services stereo, use input and output of 3D sound. 8-3) DOUBLE POWER S/W HARNESS DRA W I N G ◎ Insert COLOR WIRE in proper position.
  • Page 24 9. OPTION ◎ It is an option to change orders. MONITOR MASK You can change an order by CRT SIZE. C RT CRT SIZE is changeable between 25" and 29." C O U N T E R Number of CREDIT and COIN are displayed in participating in GAME with LED window.
