RH850 Evaluation Platform
RH850/F1KM-S4 272pin
RH850/F1KH-D8 272pin
32
PiggyBack board
Y-RH850-F1X-272PIN-PB-T2-V1
All information contained in these materials, including products and product specifications,
represents information on the product at the time of publication and is subject to change by
Renesas Electronics Corp. without notice. Please review the latest information published by
Renesas Electronics Corp. through various means, including the Renesas Technology Corp.
website (http://www.renesas.com).
The newest version of this document can be obtained from the following web location
http://www.renesas.eu/updates?oc=Y-RH850-F1X-272PIN-PB-T2-V1
www.renesa s.com
R20UT4009ED0100, Rev. 1.0
2017-07-12
Advertisement
Table of Contents
Related Manuals for Renesas RH850/F1KM-S4
Summary of Contents for Renesas RH850/F1KM-S4
- Page 1 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corp. without notice. Please review the latest information published by Renesas Electronics Corp. through various means, including the Renesas Technology Corp.
-
Page 4: Table Of Contents
Table of Contents Chapter 1 Introduction ................. 5 Chapter 2 Overview ................6 Overview ....................6 Mounting of the device ................ 7 Jumper configuration ................7 Chapter 3 Power supply ............... 9 Board power connection ..............9 Voltage distribution ................10 Chapter 4 Clock sources .............. -
Page 5: Chapter 1 Introduction
The RH850/F1x Application Board is part of the RH850 Evaluation Platform and serves as a simple and easy to use platform for evaluating the features and performance of Renesas Electronics 32-bit RH850/F1x microcontrollers. This piggyback board Y-RH850-F1X-272PIN-PB-T2-V1 can be used as a standalone board, or can be mated with a mainboard (e.g. -
Page 6: Chapter 2 Overview
F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 Chapter 2 Overview Overview Figures 1 and 2 provide the views of the Piggyback Board. Figure 1 – PiggyBoard top view Figure 2 – PiggyBoard bottom view R20UT4009ED0100 Rev.1.0 2017-07-12... -
Page 7: Mounting Of The Device
Y-RH850-F1X-272PIN-PB-T2-V1 Mounting of the device The board is designed for use with the following devices: RH850/F1KM-S4 272pin RH850/F1KH-D8 272pin The device must be placed inside the socket IC1. To insert the device, press down the lid, align the #A1 pin of the device to the #A1pin of the socket, insert the device inside the socket and release the lid. - Page 8 The RH850/F1KH-D8 device requires a supply voltage of 3.3V on its REG1VCC pin. The RH850/F1KM-S4 device requires the same supply voltage to be set to REG0VCC and REG1VCC. See the section ‘Electrical Characteristics’ in the device User’s Manual for further details.
-
Page 9: Chapter 3 Power Supply
F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 Chapter 3 Power supply Board power connection For operation of the device, a supply voltage must be connected to the board. Though a single supply voltage is sufficient for the operation of the device, two (different) voltages can be supplied to the board. -
Page 10: Voltage Distribution
The RH850/F1KH-D8 device requires a supply voltage of 3.3V on its REG1VCC pin. The RH850/F1KM-S4 device requires the same supply voltage to be set to REG0VCC and REG1VCC. See the section ‘Electrical Characteristics’ in the device User’s Manual for further details. -
Page 11: Chapter 4 Clock Sources
F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 Chapter 4 Clock sources Four external crystal oscillators for the device clock supply are provided with the board. 4.1.1 MainOsc A crystal or ceramic resonator in the range of 8MHz to 24MHz can be mounted on socket X1. -
Page 12: Chapter 5 Debug And Programming Interface
F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 Chapter 5 Debug and Programming interface For connection of the microcontroller debug and flash programming tools, the connector CN19 is provided. The signal connection of the connector CN19 is shown in the picture below: CN19 pin Device Port Device signal... -
Page 13: Chapter 6 Other Circuitry
F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 Chapter 6 Other circuitry Push button for RESET In order to issue a RESET to the device, the push-button SW1 is available. Mode Selection The PiggyBack Board gives the possibility to configure the following jumpers ... -
Page 14: Signalling Leds
F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 Signalling LEDs Eight LEDs are provided to allow visual observation of the output state of device port pins. Device pins P8_0 to P8_7 are connected to the even pins 2 to 16 of the pin header CN24, while the LEDs 1 to 8 are connected to the odd pins 1 to 15, respectively. -
Page 15: Chapter 7 Connectors For Ports Of Device
F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 Chapter 7 Connectors for ports of device Connection to each pin of the device is possible via the connectors CN5 to CN8. Note :The pin headers are directly connected to the pins, therefore special care must be taken to avoid any electrostatic or other damage to the device. - Page 16 F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 FLX1RX P10_9 FX1CLK P10_10 ETH0MDIO P12_4 ETH0MDC P12_5 ETH0RXD0 P10_1 EH0TXD0 P18_1 ETH0RXD1 P10_2 EH0TXD1 P18_2 ETH0RXD2 P10_4 EH0TXD2 P18_3 ETH0RXD3 P10_5 EH0TXD3 P18_4 ETH0RXDCLK P10_0 ETH0TXCLK P18_7 ETH0RXER P13_3 ETH0TXER ETH0CRSDV P11_12 ETH0TXEN P18_5 ETH0RXDV P11_11...
-
Page 17: Connector Cn2
F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 7.2.2 Connector CN2 Function Device Port Function Device Port CAN2Tx P0_4 CAN3Tx P1_3 CAN2Rx P0_5 CAN3Rx P1_2 CAN4Tx P1_13 CAN5Tx P0_14 CAN4Rx P1_12 CAN5Rx P0_13 LIN2Tx P0_10 LIN3Tx P1_15 LIN2Rx P0_9 LIN3Rx P1_14 LIN4Tx P1_11 LIN5Tx P8_12... - Page 18 F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 SFMA0IO0 P11_5 SFMA0IO1 P11_4 SFMA0IO2 P11_3 SFMA0IO3 P11_2 MMCA0DAT6 MMCA0DAT1 MMCA0DAT4 MMCA0DAT5 MMCA0DAT2 MMCA0DAT7 MMCA0DAT0 MMCA0CMD MMCA0CLK MMCA0DAT3 ETNB1RESET ETNB1LINK ETNB1RXD3 ETNB1TXERR ETNB1RXCLK ETNB1TXCLK ETNB1RXERR ETNB1TXD3 ETNB1CRSDV ETNB1TXEN ETNB1RXDV ETNB1COL ETNB1MDIO ETNB1TXD2 ETNB1RXD0 ETNB1TXD1 ETNB1RXD2 ETNB1MDC ETNB1RXD1...
-
Page 19: Connector Cn3
F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 7.2.3 Connector CN3 Function Device Port Function Device Port PWM00 P10_0 PWM01 P10_1 PWM02 P10_2 PWM03 P10_3 PWM04 P10_7 PWM05 P10_8 PWM06 P10_9 PWM07 P10_10 PWM08 P9_0 PWM09 P9_1 PWM10 P0_4 PWM11 P0_1 PWM12 P0_2 PWM13 P0_3... - Page 20 F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 PWMADC00 AP0_8 PWMADC01 AP0_9 PWMADC02 AP0_10 PWMADC03 AP0_11 PWMADC04 AP0_12 PWMADC05 AP0_13 PWMADC06 AP0_14 PWMADC07 AP0_15 PWMADC08 AP1_0 PWMADC09 AP1_1 PWMADC10 AP1_2 PWMADC11 AP1_3 PWMADC12 AP1_4 PWMADC13 AP1_5 PWMADC14 AP1_6 PWMADC15 AP1_7 R20UT4009ED0100 Rev.1.0 2017-07-12...
-
Page 21: Chapter 8 Mechanical Dimensions
F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 Chapter 8 Mechanical dimensions 100,00mm 50,00mm R20UT4009ED0100 Rev.1.0 2017-07-12... -
Page 22: Chapter 9 Schematic
F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 Chapter 9 Schematic R20UT4009ED0100 Rev.1.0 2017-07-12... - Page 23 F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 PUSH BUTTON 4 PIN SMD R20UT4009ED0100 Rev.1.0 2017-07-12...
- Page 24 F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 R20UT4009ED0100 Rev.1.0 2017-07-12...
-
Page 25: Chapter 10 Revision History
F1KM-S4, F1KH-D8 272pin PiggyBack board Y-RH850-F1X-272PIN-PB-T2-V1 Chapter 10 Revision History The table provides information about the major changes of the document versions. Date Version Description 2017-07-12 Initial release R20UT4009ED0100 Rev.1.0 2017-07-12...
