RH850 Evaluation Platform
RH850 Family SENT
Application Board
Y-RH850-SENT-EXT-BRD-V2
All information contained in these materials, including products and product specifications,
represents information on the product at the time of publication and is subject to change by
Renesas Electronics Corp. without notice. Please review the latest information published by
Renesas Electronics Corp. through various means, including the Renesas Technology Corp.
website (http://www.renesas.com).
The newest version of this document can be obtained from the following web location
http://www.renesas.eu/updates?oc=Y-RH850-SENT-EXT-BRD-V2#documentInfo
www.renesas.com
R12UT0014ED0100, Rev.1.00
Dec.21
Advertisement
Table of Contents
Related Manuals for Renesas RH850 Series
Summary of Contents for Renesas RH850 Series
- Page 1 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corp. without notice. Please review the latest information published by Renesas Electronics Corp. through various means, including the Renesas Technology Corp.
-
Page 2: Corporate Headquarters
Unless expressly designated as a high reliability product or a product for harsh environments in a Renesas Electronics data sheet or other Renesas Electronics document, Renesas Electronics products are not intended or authorized for use in products or systems that may pose a direct threat to human life or bodily injury (artificial life support devices or systems;... - Page 3 Products The following usage notes are applicable to all Microprocessing unit and Microcontroller unit products from Renesas. For detailed usage notes on the products covered by this document, refer to the relevant sections of the document as well as any technical updates that have been issued for the products.
-
Page 4: Table Of Contents
4.4.1 SENT TP2 [10] ......................10 4.4.2 Ground TP1 [8] ......................11 Integrated Circuits ................11 4.5.1 Renesas ZSSC4161D IC [6] ..................11 Circuits ....................11 4.6.1 Board Sensor Circuit [4] .................... 11 Mechanical dimensions ............ 12 Schematic ................13... -
Page 5: Introduction
Y-BLDC-SK-RH850F1KM-S1- RH850/F1KM-S1 Starter Kit V3 Y-RH850-X2X-MB-Tx-Vx RH850/X2X Main Board But it also can be used in combination with other Renesas Electronics evaluation tools like the Piggy Back boards or the different RH850 Family Starter Kit boards. Main features: • Build in Signal Conditioner IC ZSSC4161D •... -
Page 6: Overview
Overview The following figure provides an overview of the RH850 Family SENT application board. Figure 1: RH850 SENT Application Board Overview... -
Page 7: Getting Started
Getting Started Bill of Materials The SENT application board package contains the following type and quantity of materials. Table 3. Bill of Materials Name Quantity RH850 SENT Application Board Jumper (in separate bag) Rubber Pads Ribbon cable for X1X Main Board Basic Setup for the SENT Extension Board Before you start to operate with the SENT application board, please check the initial jumper settings according to the following table. -
Page 8: Basic Setup For The Rh850/F1Km-S1 Starter Kit
Basic Setup for the RH850/F1KM-S1 Starter Kit The board is mainly designed to operate with the RH850/F1KM-S1 Starter Kit. To setup the connection to the Starter Kit board please use the 9-Pin Sub-D connector to establish the interconnection. When you use the demo software for the SENT application board together with the RH850/F1KM-S1 Starter Kit V3, please be sure that the SENT software example is loaded onto the RH850 MCU device on the Starter Kit. -
Page 9: Power Supply
Power Supply After connecting the two boards, please supply the necessary voltage to the starter kit board to support a correct operation. Please notice that the SENT application board will only operate with 5V DC power supply. If you supply the starter kit only via the E1/E2, please make sure you don’t supply it with 3.3V. -
Page 10: Board Description
Board Description This chapter will explain the functions of the board in detail. The figure below shows an overview of the board. To provide a better explanation to the user the different functional groups are highlighted with numbers which are mentioned in the following sub chapters. -
Page 11: Jumpers
Depending on the used sensor type and its individual characteristics you need to reconfigure the ZSSC4161D so that the IC can process the measured signals with correct internal calculation values. For more information on the Signal Conditioner IC please refer to chapter 4.5.1. Jumpers Some jumpers can be used to trigger errors. -
Page 12: Ground Tp1 [8]
Renesas ZSSC4161D IC [6] The measured sensor value from the external or internal sensor circuit is processed via a Renesas Signal Conditioner IC which improves the signal and transforms the value according to the SENT protocol standard. Besides that, the IC performs several diagnostics on the sensor circuit, which are covered partly by the board hardware. -
Page 13: Mechanical Dimensions
Mechanical dimensions Figure 5: RH850 SENT Application Board dimensions... -
Page 14: Schematic
Schematic... - Page 15 Revision History SENT Application Board User’s Manual: Hardware Rev. Date Description Page Summary 1.00 Dec.21 Initial release version...
- Page 16 SENT Application Board User’s Manual: Hardware Publication Date: Rev.1.00 Dec.21 Published by: Renesas Electronics Corporation...
- Page 17 RH850 Group R12UT0014ED0100...
