User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Table of Contents Chapter 1 Introduction ................. 5 Chapter 2 Overview ................6 Overview ....................6 Mounting of the device ................ 7 Chapter 3 Jumper Configuration ............8 Chapter 4 Power supply ..............10 Board power connection ..............10 Voltage distribution ................ -
Page 5: Chapter 1 Introduction
The RH850/F1x Application Board is part of the RH850 Evaluation Platform and serves as a simple and easy to use platform for evaluating the features and performance of Renesas Electronics 32-bit RH850/F1x microcontrollers. The piggyback board (Y-RH850-F1X-100PIN-PB-T1-V3) can be used as a standalone board, or can be mated with a mainboard (Y-RH850-X1X-MB-Tx-Vx) for extended functionality. -
Page 6: Chapter 2 Overview
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Chapter 2 Overview Overview Figures 1 and 2 provide the views of the RH850-F1X-100PIN-PB-T1-V3 Piggyback Board. Device pin #1 Figure 3 – RH850-F1X-100PIN-PB-T1-V3 top view Figure 4 – RH850-F1X-100PIN-PB-T1-V3 bottom view R20UT3959ED0101, Rev. 1.01 2019-11-27... -
Page 7: Mounting Of The Device
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Mounting of the device The board is designed for use with the following devices, all in 100pin package: • RH850/F1L • RH850/R1L • RH850/F1K • RH850/F1KM-S1 • RH850/F1KM-S4 The device must be placed inside the socket IC1. To insert the device, press down the lid, align the #1 pin of the device to the #1pin of the socket, insert the device inside the socket and release the lid. -
Page 8: Chapter 3 Jumper Configuration
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Chapter 3 Jumper Configuration The function of the board can be configured via jumpers. This chapter describes the standard configuration, i.e. jumper setting for the intended devices. For the supported function of the used device, please refer to the corresponding HW user’s manual. - Page 9 User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 • green jumper JP25 for FLMDO0 always must be closed (at the position 2-3) for a ‘normal’ (user mode and debug) operation of the device. • jumpers must be set for a single “Voltage 1” (typ +5.0V) operation of the device.
-
Page 10: Chapter 4 Power Supply
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Chapter 4 Power supply Board power connection For operation of the device, a supply voltage must be connected to the board. Though a single supply voltage is sufficient for the operation of the device, two (different) voltages can be supplied to the board. Within this document the following voltages are considered as ‘typical’... -
Page 11: Voltage Distribution
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Voltage distribution The table shows the required device power supply pins and their function: Device supply pin Function REGVCC Supply for the device internal regulators for the digital logic. EVCC Supply for ports of AWO area. A0VREF Supply for ports and analog functions of ADC0. -
Page 12: Chapter 5 Clock Sources
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Chapter 5 Clock sources For mounting of the external crystal oscillator, a socket is available. 5.1.1 MainOsc A crystal or ceramic resonator in the range of 8MHz to 24MHz can be mounted on socket X1. A 8MHz and 16Mhz oscillator is supplied with the board. R20UT3959ED0101, Rev. -
Page 13: Chapter 6 Debug And Programming Interface
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Chapter 6 Debug and Programming interface For connection of the microcontroller debug and flash programming tools, the connector CN19 is provided. The signal connection of the connector CN19 is shown in the picture below: CN19 pin Device Port Device signal JP0_2 DCUTCK / LPDCLK... -
Page 14: Chapter 7 Connectors For Ports Of Device
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Chapter 7 Connectors for ports of device Connection to each pin of the device is possible via the connectors CN5 to CN8. Note :The pin headers are directly connected to the pins of the device, therefore special care must be taken to avoid any electrostatic or other damage to the device. - Page 15 User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Function Device Port Function Device Port ETH0RXD3 EH0TXD3 ETH0RXDCLK ETH0TXCLK ETH0RXER ETH0TXER ETH0CRSDV ETH0TXEN ETH0RXDV ETH0COL ETH0RESET USB0UDMF USB0UDMH USB0UDPF USB0UDPH DIGIO_0 P8_0 DIGIO_1 P8_1 DIGIO_2 P8_2 DIGIO_3 P8_3 DIGIO_4 P8_4 DIGIO_5 P8_5 DIGIO_6 P8_6 DIGIO_7 P11_0 DIGIO_8 P10_0 DIGIO_9...
-
Page 16: Connector Cn2 (Rh850-F1X-100Pin-Pb-T1-V3)
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 7.1.2 Connector CN2 (RH850-F1X-100PIN-PB-T1-V3) Function Device Port Function Device Port P0_4 CAN2Tx CAN3Tx P11_4 P0_5 CAN2Rx CAN3Rx P11_3 CAN4Tx P0_10 CAN5Tx P11_6 CAN4Rx P0_9 CAN5Rx P11_5 LIN2Tx P0_10 LIN3Tx LIN2Rx P0_9 LIN3Rx LIN4Tx P11_2 LIN5Tx LIN4Rx P11_1 LIN5Rx LIN6Tx LIN7Tx... -
Page 17: Connector Cn3 (Rh850-F1X-100Pin-Pb-T1-V3)
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Function Device Port Function Device Port 7.1.3 Connector CN3 (RH850-F1X-100PIN-PB-T1-V3) Function Device Port Function Device Port PWM00 P10_0 PWM01 P10_1 PWM02 P10_2 PWM03 P10_3 PWM04 P10_7 PWM05 P10_8 PWM06 P10_9 PWM07 P10_10 PWM08 P9_0 PWM09 P9_1 PWM10 P0_4 PWM11 P0_1... - Page 18 User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Function Device Port Function Device Port PWM40 P8_8 PWM41 P8_9 PWM42 P8_10 PWM43 P8_11 PWM44 P8_12 PWM45 P0_12 PWM46 P0_13 PWM47 P0_14 PWM48 PWM49 PWM50 PWM51 PWM52 PWM53 PWM54 PWM55 PWM56 PWM57 PWM58 PWM59 PWM60 PWM61 PWM62 PWM63 PWM64 PWM65...
-
Page 19: Chapter 8 Other Circuitry
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Chapter 8 Other circuitry Push button for RESET In order to issue a RESET to the device, the push-button SW1 is available. Mode Selection The PiggyBack Board gives the possibility to configure the following mode pins • FLMD0 via jumper JP25 •... -
Page 20: Chapter 9 Precautions
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Chapter 9 Precautions Usage of LIN15 On piggyback board V3 the LIN15 Rx/Tx signals on CN2 have been crossed. Port P10_11 is LIN15RX, but it is connected to LIN15TX. Port P10_12 is LIN15TX, but it is connected to LIN15RX. In order to fix this it is best to make the appropriate modifications on the RH850/X1x Network Main Board (Y-RH850-X1X-MB-T2-V1 or Y-RH850-X1X- MB-T2-V2) or on the RH850/X2x Main Board (Y-RH850-X2X-MB-T1-V1). -
Page 21: Adjustments On Rh850/X2X Main Board
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 9.1.2 Adjustments on RH850/X2x Main Board To be able to use LIN15 with the RH850/X2x Main Board changes are very simple. On RH850/X2x Main Board the connection of LIN15Tx and LIN15Rx to connector CN2 is by jumper JP35. This can be modified easily to accommodate the pin swap on CN2: 1. -
Page 22: Chapter 10 Mechanical Dimensions
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Chapter 10 Mechanical dimensions 100,00mm 50,00mm R20UT3959ED0101, Rev. 1.01 2019-11-27... -
Page 23: Chapter 11 Schematic
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Chapter 11 Schematic R20UT3959ED0101, Rev. 1.01 2019-11-27... - Page 24 User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 R20UT3959ED0101, Rev. 1.01 2019-11-27...
- Page 25 User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 R20UT3959ED0101, Rev. 1.01 2019-11-27...
-
Page 26: Chapter 12 Revision History
User’s Manual Y-RH850-F1X-100PIN-PB-T1-V3 Chapter 12 Revision History The table provides information about the major changes of the document versions. Date Version Description 2016-11-25 Initial release 2019-11-27 1.01 Added precaution for LIN15 signal on connector CN2 Main differences to the RH850-F1X-100PIN-PB-T1-V2: •...
