Icom IC-A210 Service Manual page 17

July 2019
The underlined parts have been updated from the addendum of the previous version, or from the original page.
[MAIN UNIT] (for IC-A210 and IC-A210E)
REF PART
NO. NO.
R21 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
7030015170 S.RES RMC1/16-222JTP (2.2 k)
7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
7030015170 S.RES RMC1/16-222JTP (2.2 k)
7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R22 7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#01] B
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#02]
7030015370 S.RES RMC1/16-104JTP (100 k) [#03]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#05]
7030003680 S.RES ERJ3GEYJ 104 V (100 k)
7030003680 S.RES ERJ3GEYJ 104 V (100 k)
7030015370 S.RES RMC1/16-104JTP (100 k) [#23]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#25]
R23 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030015210 S.RES RMC1/16-472JTP (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030015210 S.RES RMC1/16-472JTP (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R24 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030015210 S.RES RMC1/16-472JTP (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030015210 S.RES RMC1/16-472JTP (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R25 7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#01] B
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#02]
7030015370 S.RES RMC1/16-104JTP (100 k) [#03]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#05]
7030003680 S.RES ERJ3GEYJ 104 V (100 k)
7030003680 S.RES ERJ3GEYJ 104 V (100 k)
7030015370 S.RES RMC1/16-104JTP (100 k) [#23]
7030003680 S.RES ERJ3GEYJ 104 V (100 k) [#25]
R26 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
7030003440 S.RES ERJ3GEYJ 102 V (1 k)
7030015130 S.RES RMC1/16-102JTP (1 k)
7030003440 S.RES ERJ3GEYJ 102 V (1 k)
7030003440 S.RES ERJ3GEYJ 102 V (1 k)
7030003440 S.RES ERJ3GEYJ 102 V (1 k)
7030015130 S.RES RMC1/16-102JTP (1 k)
7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R27 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
7030003440 S.RES ERJ3GEYJ 102 V (1 k)
7030015130 S.RES RMC1/16-102JTP (1 k)
7030003440 S.RES ERJ3GEYJ 102 V (1 k)
7030003440 S.RES ERJ3GEYJ 102 V (1 k)
7030003440 S.RES ERJ3GEYJ 102 V (1 k)
7030015130 S.RES RMC1/16-102JTP (1 k)
7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R28 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
7030003560 S.RES ERJ3GEYJ 103 V (10 k)
7030015250 S.RES RMC1/16-103JTP (10 k)
7030003560 S.RES ERJ3GEYJ 103 V (10 k)
7030003560 S.RES ERJ3GEYJ 103 V (10 k)
7030003560 S.RES ERJ3GEYJ 103 V (10 k)
7030015250 S.RES RMC1/16-103JTP (10 k)
7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R29 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030015210 S.RES RMC1/16-472JTP (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
7030015210 S.RES RMC1/16-472JTP (4.7 k)
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R31 7030003630 S.RES ERJ3GEYJ 393 V (39 k)
7030003630 S.RES ERJ3GEYJ 393 V (39 k)
7030015320 S.RES RMC1/16-393JTP (39 k)
7030003630 S.RES ERJ3GEYJ 393 V (39 k)
7030003630 S.RES ERJ3GEYJ 393 V (39 k)
7030003630 S.RES ERJ3GEYJ 393 V (39 k)
7030015320 S.RES RMC1/16-393JTP (39 k)
7030003630 S.RES ERJ3GEYJ 393 V (39 k)
R32 7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
7030015520 S.RES RMC1/16JPTP
7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
7030015520 S.RES RMC1/16JPTP
7030003860 S.RES ERJ3GE JPW V
R33 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
7030003560 S.RES ERJ3GEYJ 103 V (10 k)
7030015250 S.RES RMC1/16-103JTP (10 k)
7030003560 S.RES ERJ3GEYJ 103 V (10 k)
7030003560 S.RES ERJ3GEYJ 103 V (10 k)
7030003560 S.RES ERJ3GEYJ 103 V (10 k)
7030015250 S.RES RMC1/16-103JTP (10 k)
7030003560 S.RES ERJ3GEYJ 103 V (10 k)
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
[#01] T 23.1/63.8
[#02]
[#03]
[#05]
[#11]
[#21]
[#23]
[#25]
57.1/55.6
[#11]
[#21]
[#01] B 60.2/53.1
[#02]
[#03]
[#05]
[#11]
[#21]
[#23]
[#25]
[#01] B 90.7/61.9
[#02]
[#03]
[#05]
[#11]
[#21]
[#23]
[#25]
93.7/61.9
[#11]
[#21]
[#01] T 25.5/68.3
[#02]
[#03]
[#05]
[#11]
[#21]
[#23]
[#25]
[#01] T 25.7/62.8
[#02]
[#03]
[#05]
[#11]
[#21]
[#23]
[#25]
[#01] T 178.5/104.1
[#02]
[#03]
[#05]
[#11]
[#21]
[#23]
[#25]
[#01] B 38.8/57.0
[#02]
[#03]
[#05]
[#11]
[#21]
[#23]
[#25]
[#01] B 22.1/129.1
[#02]
[#03]
[#05]
[#11]
[#21]
[#23]
[#25]
[#01] B 58.2/135.2
[#02]
[#03]
[#05]
[#11]
[#21]
[#23]
[#25]
[#01] B 25.4/52.0
[#02]
[#03]
[#05]
[#11]
[#21]
[#23]
[#25]
(Amended page)
[MAIN UNIT] (for IC-A210 and IC-A210E)
H/V REF PART
NO. NO.
R34 7030003520 S.RES
7030003520 S.RES
7030015210 S.RES
7030003520 S.RES
7030003520 S.RES
7030003520 S.RES
7030015210 S.RES
7030003520 S.RES
R35 7030003520 S.RES
7030003520 S.RES
7030015210 S.RES
7030003520 S.RES
7030003520 S.RES
7030003520 S.RES
7030015210 S.RES
7030003520 S.RES
R36 7030003480 S.RES
7030003480 S.RES
7030015170 S.RES
7030003480 S.RES
7030003480 S.RES
7030003480 S.RES
7030015170 S.RES
7030003480 S.RES
R37 7030003560 S.RES
7030003560 S.RES
7030015250 S.RES
7030003560 S.RES
7030003560 S.RES
7030003560 S.RES
7030015250 S.RES
7030003560 S.RES
R39 7030003480 S.RES
7030003480 S.RES
7030015170 S.RES
7030003480 S.RES
7030003480 S.RES
7030003480 S.RES
7030015170 S.RES
7030003480 S.RES
R40 7030003440 S.RES
7030003440 S.RES
7030015130 S.RES
7030003440 S.RES
7030003440 S.RES
7030003440 S.RES
7030015130 S.RES
7030003440 S.RES
R41 7030003740 S.RES
7030003740 S.RES
7030015430 S.RES
7030003740 S.RES
7030003740 S.RES
7030003740 S.RES
7030015430 S.RES
7030003740 S.RES
R42 7030003620 S.RES
7030003620 S.RES
7030015310 S.RES
7030003620 S.RES
7030003620 S.RES
7030003620 S.RES
7030015310 S.RES
7030003620 S.RES
R43 7030003740 S.RES
7030003740 S.RES
7030015430 S.RES
7030003740 S.RES
7030003740 S.RES
7030003740 S.RES
7030015430 S.RES
7030003740 S.RES
R44 7030006220 S.RES
R45 7030003680 S.RES
7030003680 S.RES
7030015370 S.RES
7030003680 S.RES
7030003680 S.RES
7030003680 S.RES
7030015370 S.RES
7030003680 S.RES
R46 7030003520 S.RES
7030003520 S.RES
7030015210 S.RES
7030003520 S.RES
7030003520 S.RES
7030003520 S.RES
7030015210 S.RES
7030003520 S.RES
R47 7030003790 S.RES
7030003790 S.RES
7030015470 S.RES
7030003790 S.RES
7030003790 S.RES
7030003790 S.RES
7030015470 S.RES
7030003790 S.RES
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
5-4g
DESCRIPTION M.
ERJ3GEYJ 472 V (4.7 k) [#01] B
ERJ3GEYJ 472 V (4.7 k) [#02]
RMC1/16-472JTP (4.7 k) [#03]
ERJ3GEYJ 472 V (4.7 k) [#05]
ERJ3GEYJ 472 V (4.7 k) [#11]
ERJ3GEYJ 472 V (4.7 k) [#21]
RMC1/16-472JTP (4.7 k) [#23]
ERJ3GEYJ 472 V (4.7 k) [#25]
ERJ3GEYJ 472 V (4.7 k) [#01] B
ERJ3GEYJ 472 V (4.7 k) [#02]
RMC1/16-472JTP (4.7 k) [#03]
ERJ3GEYJ 472 V (4.7 k) [#05]
ERJ3GEYJ 472 V (4.7 k) [#11]
ERJ3GEYJ 472 V (4.7 k) [#21]
RMC1/16-472JTP (4.7 k) [#23]
ERJ3GEYJ 472 V (4.7 k) [#25]
ERJ3GEYJ 222 V (2.2 k) [#01] T
ERJ3GEYJ 222 V (2.2 k) [#02]
RMC1/16-222JTP (2.2 k) [#03]
ERJ3GEYJ 222 V (2.2 k) [#05]
ERJ3GEYJ 222 V (2.2 k) [#11]
ERJ3GEYJ 222 V (2.2 k) [#21]
RMC1/16-222JTP (2.2 k) [#23]
ERJ3GEYJ 222 V (2.2 k) [#25]
ERJ3GEYJ 103 V (10 k) [#01] B
ERJ3GEYJ 103 V (10 k) [#02]
RMC1/16-103JTP (10 k) [#03]
ERJ3GEYJ 103 V (10 k) [#05]
ERJ3GEYJ 103 V (10 k) [#11]
ERJ3GEYJ 103 V (10 k) [#21]
RMC1/16-103JTP (10 k) [#23]
ERJ3GEYJ 103 V (10 k) [#25]
ERJ3GEYJ 222 V (2.2 k) [#01] T
ERJ3GEYJ 222 V (2.2 k) [#02]
RMC1/16-222JTP (2.2 k) [#03]
ERJ3GEYJ 222 V (2.2 k) [#05]
ERJ3GEYJ 222 V (2.2 k) [#11]
ERJ3GEYJ 222 V (2.2 k) [#21]
RMC1/16-222JTP (2.2 k) [#23]
ERJ3GEYJ 222 V (2.2 k) [#25]
ERJ3GEYJ 102 V (1 k) [#01] T
ERJ3GEYJ 102 V (1 k) [#02]
RMC1/16-102JTP (1 k) [#03]
ERJ3GEYJ 102 V (1 k) [#05]
ERJ3GEYJ 102 V (1 k) [#11]
ERJ3GEYJ 102 V (1 k) [#21]
RMC1/16-102JTP (1 k) [#23]
ERJ3GEYJ 102 V (1 k) [#25]
ERJ3GEYJ 334 V (330 k) [#01] T
ERJ3GEYJ 334 V (330 k) [#02]
RMC1/16-334JTP (330 k) [#03]
ERJ3GEYJ 334 V (330 k) [#05]
ERJ3GEYJ 334 V (330 k) [#11]
ERJ3GEYJ 334 V (330 k) [#21]
RMC1/16-334JTP (330 k) [#23]
ERJ3GEYJ 334 V (330 k) [#25]
ERJ3GEYJ 333 V (33 k) [#01] B
ERJ3GEYJ 333 V (33 k) [#02]
RMC1/16-333JTP (33 k) [#03]
ERJ3GEYJ 333 V (33 k) [#05]
ERJ3GEYJ 333 V (33 k) [#11]
ERJ3GEYJ 333 V (33 k) [#21]
RMC1/16-333JTP (33 k) [#23]
ERJ3GEYJ 333 V (33 k) [#25]
ERJ3GEYJ 334 V (330 k) [#01] B
ERJ3GEYJ 334 V (330 k) [#02]
RMC1/16-334JTP (330 k) [#03]
ERJ3GEYJ 334 V (330 k) [#05]
ERJ3GEYJ 334 V (330 k) [#11]
ERJ3GEYJ 334 V (330 k) [#21]
RMC1/16-334JTP (330 k) [#23]
ERJ3GEYJ 334 V (330 k) [#25]
ERJ12YJ470U (47) B
ERJ3GEYJ 104 V (100 k) [#01] B
ERJ3GEYJ 104 V (100 k) [#02]
RMC1/16-104JTP (100 k) [#03]
ERJ3GEYJ 104 V (100 k) [#05]
ERJ3GEYJ 104 V (100 k) [#11]
ERJ3GEYJ 104 V (100 k) [#21]
RMC1/16-104JTP (100 k) [#23]
ERJ3GEYJ 104 V (100 k) [#25]
ERJ3GEYJ 472 V (4.7 k) [#01] B
ERJ3GEYJ 472 V (4.7 k) [#02]
RMC1/16-472JTP (4.7 k) [#03]
ERJ3GEYJ 472 V (4.7 k) [#05]
ERJ3GEYJ 472 V (4.7 k) [#11]
ERJ3GEYJ 472 V (4.7 k) [#21]
RMC1/16-472JTP (4.7 k) [#23]
ERJ3GEYJ 472 V (4.7 k) [#25]
ERJ3GEYJ 824 V (820 k) [#01] B
ERJ3GEYJ 824 V (820 k) [#02]
RMC1/16-824JTP (820 k) [#03]
ERJ3GEYJ 824 V (820 k) [#05]
ERJ3GEYJ 824 V (820 k) [#11]
ERJ3GEYJ 824 V (820 k) [#21]
RMC1/16-824JTP (820 k) [#23]
ERJ3GEYJ 824 V (820 k) [#25]
H/V
LOCATION
16.7/48.5
18.2/60.4
39.9/85.7
24.1/59.6
39.9/76.4
23.1/57.4
19.5/50.3
19.8/128.4
15.3/55.6
74.4/65.4
72.3/51.8
72.3/47.8
18.7/58.5
