Icom IC-A210 Service Manual page 129

August 2015
[PA-B UNIT]
REF PARTS
DESCRIPTION
NO. NO.
C515 4030007070 S.CER C1608 CH 1H 330J-T
C516 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C517 4030020730 S.CER GRM31A5C2J471JW01D
C518 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C519 4030007010 S.CER C1608 CH 1H 100D-T
C520 4030007100 S.CER C1608 CH 1H 560J-T
C521 4030007130 S.CER C1608 CH 1H 101J-T ATEX
C522 4030007050 S.CER C1608 CH 1H 220J-T
C523 4550007500 S.TAN F931D106MBABMA
C524 4030007110 S.CER C1608 CH 1H 680J-T
C525 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C527 4030006900 S.CER C1608 JB 1H 103K-T ATEX
C528 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C529 4030007060 S.CER C1608 CH 1H 270J-T
C531 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C532 4030007100 S.CER C1608 CH 1H 560J-T
C534 4030006900 S.CER C1608 JB 1H 103K-T ATEX
C535 4550007540 S.TAN F931C155MAABMA
C536 4030007130 S.CER C1608 CH 1H 101J-T ATEX
C537 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C538 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C539 4030006880 S.CER C1608 JB 1H 472K-T
C540 4030020730 S.CER GRM31A5C2J471JW01D
C542 4030007140 S.CER C1608 CH 1H 121J-T
C543 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C544 4030020800 S.CER GRM31A5C2J680JW01D
C545 4030006900 S.CER C1608 JB 1H 103K-T ATEX
C547 4030021290 S.CER GQM22M5C2H220JB01L
C548 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C549 4030020750 S.CER GRM31A5C2J220JW01D
C550 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C551 4030020750 S.CER GRM31A5C2J220JW01D
C552 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C553 4030010780 S.CER C1608 CH 1H 1R5C-T
C554 4030007020 S.CER C1608 CH 1H 120J-T
C555 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C556 4030010780 S.CER C1608 CH 1H 1R5C-T
C557 4030007020 S.CER C1608 CH 1H 120J-T
C558 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C559 4030006900 S.CER C1608 JB 1H 103K-T ATEX
C560 4030020750 S.CER GRM31A5C2J220JW01D
C561 4030019420 S.CER GRM31A7U2J102JW31D
C562 4030019420 S.CER GRM31A7U2J102JW31D
C563 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C565 4030020740 S.CER GRM31A5C2J180JW01D
C566 4030007030 S.CER C1608 CH 1H 150J-T
C567 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C568 4030007130 S.CER C1608 CH 1H 101J-T ATEX
C569 4030019420 S.CER GRM31A7U2J102JW31D
C570 4030007070 S.CER C1608 CH 1H 330J-T
C572 4030020750 S.CER GRM31A5C2J220JW01D
C575 4030020740 S.CER GRM31A5C2J180JW01D
C576 4030020740 S.CER GRM31A5C2J180JW01D
C577 4030011100 S.CER GRM31M2C2H8R0DV01L
(GRM42-6)
C578 4030020770 S.CER GRM31A5C2J330JW01D
C582 4030020740 S.CER GRM31A5C2J180JW01D
C583 4550007660 S.TAN F931E105MAABMA
C585 4030020790 S.CER GRM31A5C2J560JW01D
C587 4030011090 S.CER GRM31M2C2H7R0DV01L
(GRM42-6)
C588 4030018980 S.CER C1608 JB 1H 104K-T ATEX
C591 4030018980 S.CER C1608 JB 1H 104K-T ATEX
C592 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C595 4030007020 S.CER C1608 CH 1H 120J-T
C596 4030007020 S.CER C1608 CH 1H 120J-T
C597 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C598 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C599 4030006860 S.CER C1608 JB 1H 102K-T ATEX
C600 4030011070 S.CER GRM31M2C2H5R0CY21L
(GRM42-6)
C601 4030018980 S.CER C1608 JB 1H 104K-T ATEX
C602 4030006850 S.CER C1608 JB 1H 471K-T
J500 6510011591 CON B2P-VH(LF)(SN)
J501 6510030790 CON SJ070010 (TMP-S01X-C1)
J502 6510023261 S.CON B6B-PH-SM4-TB(LF)(SN)
J503 6510030790 CON SJ070010 (TMP-S01X-C1)
J504 6510030790 CON SJ070010 (TMP-S01X-C1)
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
(Amended page)
H/V
M.
LOCATION
T 13.7/28.4
T 17.8/24.6
T 23.4/23.5
T 27.2/20.1
T 27.9/26.4
T 29.2/30.9
T 31.4/30.4
T 38.0/31.8
T 24.1/3.1
T 38.7/27.4
T 19.8/4.2
T 24.1/6.2
T 25.3/6.2
T 35.3/23.1
T 25.8/12.9
T 37.2/20.8
T 21.9/13.6
T 50.6/7.3
T 28.1/17.1
T 51.3/9.1
T 85.7/9.9
T 84.3/9.9
T 45.9/28.5
T 81.0/9.9
T 82.3/9.9
T 74.0/28.3
T 29.9/4.0
T 84.6/26.7
T 29.9/2.8
T 94.2/29.2
T 101.0/19.3
T 96.7/29.2
T 110.1/7.2
T 99.0/24.5
T 99.0/21.7
T 102.5/16.8
T 104.7/25.6
T 104.7/22.7
T 104.7/19.9
T 108.9/7.2
T 106.2/30.2
T 108.2/9.5
T 110.9/27.1
T 106.8/20.4
T 118.2/20.1
T 119.2/6.5
T 125.8/5.4
T 14.9/12.7
T 115.4/25.2
T 119.2/11.0
T 117.4/29.1
T 127.9/32.6
T 125.8/33.6
T 129.4/25.4
T 135.8/30.2
T 146.3/25.8
T 35.2/15.0
T 68.1/26.2
T 110.8/19.6
T 95.9/14.0
T 24.5/9.0
T 36.8/10.8
T 135.3/19.8
T 130.9/19.8
T 133.3/17.7
T 128.9/17.7
T 133.3/15.1
T 152.5/11.9
T 31.2/14.7
T 35.6/10.8
T 39.6/4.2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
19
S.=Surface mount
