PROAIM FLCM-GAXS Assembly Manual

G-axis stabilizer support system

What's In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

Dovetail Quick

Release Plate

Gimbal Handle

Proaim G-Axis Stabilizer Support System

No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright

G-Axis Stabilizer Support System

A s s e m b l y M a n u a l

Gimbal

Grip

statutes or in writing by the Publisher.

Bag Packing

Base Weight

Platform

Telescopic Central

Gimbal

Post

Support

(FLCM-GAXS)

Ratchet Knob

3/16mm Allen

key

Table of Contents

Need help?

Do you have a question about the FLCM-GAXS and is the answer not in the manual?

Page 1 Gimbal Grip Gimbal Handle Bag Packing Base Weight Ratchet Knob Platform Proaim G-Axis Stabilizer Support System 3/16mm Allen Telescopic Central Gimbal Post Support All rights reserved. No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means, electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright statutes or in writing by the Publisher.
Page 2 Stabilizer Support System Setup  You can attach/detach weights to make the base platform balance according to your set- up weight.  Mount the weights on the base weight platform and secure them properly as shown in the image.  Using an allen key, loosen the locking screw on the central post such that telescoping post extends outwards...
Page 3 Flycam G-axis is compatible with Single-Grip Gimbals such as the DJI RS 2, RSC 2, Ronin-S, Zhiyun-Tech CRANE 2S and 3S, Moza Air 2, and more. YOUR PROAIM G-AXIS STABILIZER SUPPORT SYSTEM ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES)
Page 4 Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspection and evaluation by us.
